CP PLUS CP-UVC-EC4K08L2C-D is a 4K 8MP fisheye camera featuring 180° panoramic view, 15m IR night vision, IP67 weatherproof, and advanced WDR for clear surveillance in any lighting conditions.
Pick up from the FGTECH Store To pick up today
0-1 Days
Free
Courier delivery Our courier will deliver to the specified address
4-7 Days
Free
Porter / WeFast Currently available only in Mumbai
0-1 Days
To be paid directly to service vendor
Fast Delivery ( By Air ) We will ship from your product By Air to nearest center to speed up the delivery
2-4 Days
Start from Rs250 Extra
The CP PLUS CP-UVC-EC4K08L2C-D is a premium 4K WDR HDCVI IR Fisheye Camera designed to deliver exceptional panoramic surveillance with superior image clarity. This advanced fisheye camera features an 8 Megapixel 1/2″ progressive scan CMOS sensor, capable of capturing ultra-high-definition 4K resolution video at up to 15 frames per second. Perfect for expansive surveillance areas, it offers a wide 180° angle of view with multiple correction modes, including original, panoramic, and double panoramic, making it versatile for various security setups.
The CP PLUS CP-UVC-EC4K08L2C-D model supports a powerful Wide Dynamic Range (WDR) of 120dB to ensure excellent visibility in challenging lighting conditions such as glare and shadows. The IR illumination reaches up to 15 meters, enabling efficient night vision capabilities. Additional cutting-edge features include Day/Night functionality with ICR, 2D/3D digital noise reduction, automatic white balance (AWB), automatic gain control (AGC), backlight compensation (BLC), and highlight compensation (HLC).
Designed to withstand tough environments, the CP PLUS CP-UVC-EC4K08L2C-D is rated IP67 for waterproofing and IK10 for vandal resistance. CP PLUS CP-UVC-EC4K08L2C-D supports up to 500 meters of transmission over RG59 coaxial cable, making this the ideal solution for robust enterprise-level security surveillance.
Key Features:
8MP 1/2″ CMOS sensor with 4K resolution (3840×2160)
180° panoramic fisheye lens with multiple correction modes
120dB Wide Dynamic Range (WDR) for superior light balancing
IR night vision with range up to 15 meters
IP67 weatherproof and IK10 vandal-resistant housing
Day/Night with ICR, 2D/3D-DNR, AWB, AGC, BLC, HLC
Up to 500m transmission on RG59 coaxial cable
Built-in microphone for audio monitoring
| Specification | Details |
|---|---|
| Model | CP-UVC-EC4K08L2C-D |
| Brand | CP PLUS |
| Sensor Type | 1/2" 8 Megapixel Progressive Scan CMOS |
| Resolution | 8MP (3840×2160), 4MP (2560×1440) |
| Max Frame Rate | 15 fps @ 4K |
| Lens | 2.5mm Panoramic Fisheye Lens |
| Angle of View | 180° |
| Minimum Illumination | 0.01 Lux @ F2.0 (Color), 0 Lux IR ON |
| IR Range | Up to 15 meters |
| Wide Dynamic Range (WDR) | 120 dB |
| Day/Night Mode | IR Cut Filter Removal (ICR) |
| Noise Reduction | 2D/3D Digital Noise Reduction |
| Video Output | HDCVI, CVBS |
| White Balance | Auto/Manual |
| Gain Control (AGC) | Auto |
| Backlight Compensation | BLC / HLC |
| Signal-to-Noise Ratio | More than 65 dB |
| Alarm Input/Output | 2 channels IN / 1 channel OUT |
| Audio | Built-in Microphone |
| OSD Language Support | Multi-language |
| Operating Temperature | -30°C to +60°C, ≤ 90% RH |
| Power Source | DC12V ± 25% |
| Power Consumption | 7.4W (IR ON) |
| Dimensions (mm) | 150 (L) x 50.7 (W) |
| Weight | 0.56 kg |
| Protection | IP67 Weatherproof, IK10 Vandal Resistant |
| Transmission Distance | Up to 500m with RG59 Coaxial Cable |
| Certification | CE, FCC, ROHS Compliant |
