CP PLUS CP-UNC-TA41L6C-Q 4MP IP Bullet Camera | IR 60m | Built-in Mic | IP67 (6 mm)

The CP-UNC-TA41L6C-Q is a 4MP PoE network bullet camera designed for outdoor surveillance, featuring a built-in microphone, 60 m infrared night vision, and wired Ethernet connectivity.

Pick up from the FGTECH Store

To pick up today

0-1 Days

Courier delivery

Our courier will deliver to the specified address

4-7 Days

Porter / WeFast

Currently available only in Mumbai

0-1 Days

To be paid directly to service vendor

Fast Delivery ( By Air )

We will ship from your product By Air to nearest center to speed up the delivery

2-4 Days

Start from Rs250 Extra

SKU: FGIN57C8M7V1 Categories: Surveillance and Security, IP Cameras Brand: CP Plus

Description

The CP-UNC-TA41L6C-Q is a fixed-lens 4MP network bullet camera from CP PLUS, designed for wired outdoor video surveillance systems requiring Power over Ethernet and audio recording.

It captures video at up to 2688 × 1520 resolution and supports triple-stream transmission using Instastream, H.265, and H.264 compression formats. A built-in microphone enables audio recording, while a 6 mm fixed lens and infrared illumination provide clear monitoring in low-light and night conditions.

The CP-UNC-TA41L6C-Q is housed in an IP67-rated enclosure for outdoor use and connects via RJ-45 Ethernet. Power can be supplied either through PoE (802.3af) or a 12 V DC adapter. This model does not include Wi-Fi, onboard storage, a speaker, or pan-tilt-zoom functionality and is intended to operate with a compatible NVR.

It supports standard ONVIF profiles, allowing integration with compatible third-party NVRs and video management systems over a wired network.

Best suited for

Wired PoE-based CCTV installations
Outdoor perimeter and entrance monitoring
Locations requiring audio recording via built-in microphone
Homes, small retail stores, and small to medium business premises

Not suitable for

Wi-Fi-only surveillance systems
Two-way audio communication use cases
Standalone recording without an NVR
PTZ or motorized camera requirements

Product Details

General • Product Type: Network IP Bullet Camera
• Brand: CP PLUS
• Model: CP-UNC-TA41L6C-Q

Image & Video • Image Sensor: 1/2.8" 4MP PS CMOS
• Effective Pixels: 2688 (H) × 1520 (V)
• Maximum Resolution: 4MP (2688 × 1520)
• Video Frame Rate: Up to 25/30 fps
• Video Compression: Instastream, H.265, H.264, H.264H, H.264B, MJPEG
• Stream Capability: Triple stream
• Day/Night Mode: Auto (ICR) / Color / B/W
• Minimum Illumination: 0.001 lux (Color), 0.0001 lux (B/W), 0 lux (IR on)
• S/N Ratio: >58 dB

Lens • Lens Type: Fixed-focal
• Focal Length: 6 mm
• Maximum Aperture: F1.4
• Lens Mount: M12
• Angle of View (Horizontal): 49°
• Angle of View (Vertical): 26°
• Angle of View (Diagonal): 57°
• Close Focus Distance: 3.2 m

Infrared & Night Vision • IR Illumination: Supported
• IR Range: 60 m
• IR LEDs: 4
• Smart IR: Supported

Audio • Built-in Microphone: Supported
• Speaker: Not supported
• Audio Compression: G.711a, G.711Mu, PCM, G.726, AAC

Video Processing • Back Light Compensation: BLC, HLC, DWDR
• Noise Reduction: 3D NR
• White Balance: Auto, Natural, Street Lamp, Outdoor, Manual, Regional Custom
• Gain Control: Auto, Manual
• Shutter Speed: 1/3 s to 1/100,000 s

Smart & Analytics • Motion Detection: Supported
• Human Detection: Supported
• Privacy Mask: Supported
• ROI (Region of Interest): Supported
• Smart Search: Not specified by manufacturer

Connectivity / Interfaces • Ethernet: RJ-45 (10/100 Base-T)
• Wi-Fi: Not supported
• ONVIF Support: Profile S, Profile G, Profile T
• Network Protocols: IPv4, IPv6, HTTP, HTTPS, TCP/IP, UDP, RTSP, RTP, NTP, DNS, DHCP, SNMP v3, TLS 1.2, SSL, IGMP, PPPoE, SMTP, ICMP, NFS, SFTP

Power • Power Source: 12 V DC / PoE (802.3af)
• Power Consumption (Basic): 2 W (DC), 2.9 W (PoE)
• Power Consumption (Max): 5.3 W (DC), 6.8 W (PoE)

Physical & Environmental • Weatherproof Rating: IP67
• Operating Temperature: –40 °C to +60 °C
• Operating Humidity: ≤95%
• Storage Temperature: –40 °C to +60 °C
• Storage Humidity: ≤95%
• Casing Material: Metal + Plastic
• Dimensions: 197.9 × 80.2 × 76.2 mm
• Weight: 310 g

System & Compatibility • NVR Requirement: Required
• Browser Support: IE, Chrome, Firefox
• User/Host Capacity: 6 users

Certifications • Certifications: ISO 9001:2015, ISO 20000-1:2018, CE, FCC, RoHS, BIS, STQC

Datasheet

CP PLUS CP-UNC-TA41L6C-Q
