CP Plus CP-UNP-E3221L18-DAQ is a 2MP PTZ IP camera featuring 32x optical zoom, 180-meter IR range, PoE+ support, and IP67-rated housing for outdoor surveillance applications.
Pick up from the FGTECH Store To pick up today
0-1 Days
Free
Courier delivery Our courier will deliver to the specified address
4-7 Days
Free
Porter / WeFast Currently available only in Mumbai
0-1 Days
To be paid directly to service vendor
Fast Delivery ( By Air ) We will ship from your product By Air to nearest center to speed up the delivery
2-4 Days
Start from Rs250 Extra
The CP-UNP-E3221L18-DAQ is a fixed-specification 2MP network PTZ camera designed for long-range outdoor surveillance requiring high optical zoom and precise pan-tilt control.
CP-UNP-E3221L18-DAQ uses a 1/2.8-inch CMOS image sensor and delivers Full HD video at up to 25/30 fps. The camera supports 32x optical zoom and 16x digital zoom, enabling distant subject monitoring without loss of optical detail.
For low-light conditions, the camera integrates IR illumination with an effective range of up to 180 meters and supports Starlight technology for improved visibility in near-dark environments. Wide Dynamic Range (120 dB), 2D/3D noise reduction, defog, and backlight compensation are supported.
The unit is built for outdoor installation with IP67 weather resistance and IK10 vandal protection. Power can be supplied using PoE+ (802.3at) or 24V DC. Network connectivity is provided via Ethernet only.
The camera does not include a built-in microphone or speaker. Audio input and output ports are available for optional external audio devices. Recording can be performed via NVR, NAS, FTP/SFTP, or microSD card (up to 512 GB).
Long-range outdoor surveillance requiring optical zoom
Large premises such as campuses, parking areas, perimeters, and industrial sites
Installations needing PTZ presets, tours, and auto-tracking
Ethernet-based surveillance networks with PoE+ support
Installations requiring built-in microphone or speaker
Wi-Fi-only camera deployments
Battery-powered surveillance setups
Compact indoor monitoring applications
General:
Product Type: Network PTZ Camera
Brand: CP PLUS
Model: CP-UNP-E3221L18-DAQ
Image Sensor & Video:
Image Sensor: 1/2.8 inch 2MP PS CMOS
Effective Pixels: 1920 × 1080
Maximum Resolution: 2MP (1920 × 1080)
Frame Rate: Up to 25/30 fps
Video Format: PAL / NTSC
Electronic Shutter Speed: 1/1 s – 1/30,000 s
Signal-to-Noise Ratio: ≥ 55 dB
Lens & Zoom:
Focal Length: 4.5 mm – 144 mm
Optical Zoom: 32x
Digital Zoom: 16x
Maximum Aperture: F1.6 – F4.0
Angle of View (Horizontal): 58.4° – 3.0°
Angle of View (Vertical): 33.4° – 1.7°
Angle of View (Diagonal): 66.4° – 3.4°
Focus Control: Auto / Semi-auto / Manual
Iris Control: Auto / Manual
Close Focus Distance: 0.1 m – 1.5 m
PTZ Functions:
Pan Range: 0° – 360° (Endless)
Tilt Range: –15° to +90°
Auto Flip: 180°
Presets: Up to 300
Scans: 5
Tours: 8
Patterns: 5
Preset Speed: Pan 400°/s, Tilt 300°/s
Manual Speed: Pan 0.1°/s – 300°/s, Tilt 0.1°/s – 200°/s
Power-Off Memory: Supported
Low Light & Image Enhancement:
Minimum Illumination (Color): 0.005 lux @ F1.6
Minimum Illumination (B/W): 0.0005 lux @ F1.6
Minimum Illumination (IR On): 0 lux
Day/Night Mode: Auto (ICR) / Color / B/W
Wide Dynamic Range: 120 dB
Noise Reduction: 2D NR / 3D NR
Backlight Compensation: BLC / HLC / WDR
Defog: Electronic
Image Stabilization: Electronic (EIS)
Image Rotation: 180°
Infrared & Night Vision:
IR Range: Up to 180 m
IR LEDs: 4
IR Control: Zoom Priority / Manual / Smart IR / Off
Streaming & Compression:
Stream Capability: Quad Stream
Video Compression: Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Sub Stream 1)
Bit Rate Control: CBR / VBR
Bit Rate (H.265): 25 kbps – 6400 kbps
Bit Rate (H.264): 64 kbps – 10496 kbps
Audio:
Built-in Microphone: No
Built-in Speaker: No
Audio Input: 1 Channel
Audio Output: 1 Channel
Audio Compression: PCM, G.711A, G.711MU, G.726, MPEG2-Layer2, G.722.1, AAC
Analytics & Smart Features:
Motion Detection: Supported
SMD: Supported
Auto Tracking: Supported
ROI: Supported
IVS: Supported (Optional)
Privacy Masking: Supported (Up to 24 areas)
Network & Protocols:
Ethernet: 1 × RJ-45 (10/100 Base-T)
Wi-Fi: Not supported
Network Protocols: IPv4, IPv6, TCP/IP, UDP, HTTP, HTTPS, RTSP, RTSPS, SNMP v3, ONVIF (Profile S, Profile G, Profile T), NTP, DHCP, DNS, SMTP, FTP, SFTP, PPPoE, ICMP, SSL
Storage:
Local Storage: MicroSD Card (Up to 512 GB)
Network Storage: NAS, SFTP
Alarm & I/O:
Alarm Input: 2
Alarm Output: 1
Alarm Events: Motion, Tampering, Audio Detection, Network Disconnection, IP Conflict, Storage Events
Cyber Security:
Encryption: AES 256-bit
Security Features: Configuration encryption, Trusted boot, Trusted upgrade, Account lockout, HTTPS, IP/MAC filtering, Security logs
Power:
Power Supply: 24 V DC, 2.5 A ±25%
PoE: PoE+ (802.3at)
Power Consumption: Basic 8 W, Maximum 18.5 W
Physical & Environmental:
Ingress Protection: IP67
Impact Protection: IK10
Lightning Protection: TVS 6000 V
Operating Temperature: –40°C to +70°C
Operating Humidity: ≤ 95% RH
Dimensions: 33.2 cm × 19.0 cm (Diameter)
Weight: 4.6 kg
Certification:
Certification: ISO9001
