Mikrotik Chateau LTE6 ax | High-Performance LTE AX Router for Reliable Connectivity
Warranty Period :- 1 Year
Mikrotik Chateau LTE6 ax access point with even faster wireless and an improved CPU. For mobile network users who need that extra speed and responsiveness of Gen6 ax wireless. Perfect for large, busy households or medium-sized offices.
₹24,999.00 Original price was: ₹24,999.00.₹23,880.00Current price is: ₹23,880.00. Inc. tax (₹20,237.29Exc. Tax)
Out of stock
Out of stock
Description
Mikrotik Chateau LTE6 ax is a powerful and advanced router designed for delivering fast and reliable internet connectivity, particularly suited for last-mile solutions. Combining WiFi 6 (802.11ax) technology with LTE support, this router provides superior performance, coverage, and device capacity, making it perfect for households or offices in need of robust internet solutions.
Key Features:
- LTE Cat6 Modem: Ensures high-speed LTE connectivity with up to 300 Mbps download speeds for smooth browsing, streaming, and data transfer.
- WiFi 6 Technology: Next-generation 802.11ax standard for higher data rates, increased efficiency, and better support for multiple devices.
- Dual-Band WiFi: Operates on both 2.4GHz and 5GHz bands, enhancing network flexibility and stability.
- High-Performance Hardware: Equipped with a powerful quad-core CPU to handle extensive network demands.
- Secure and Customizable: Built with MikroTik’s RouterOS for advanced customization and comprehensive security features.
Applications:
- Rural and Remote Areas: Ideal for providing reliable internet in locations with limited wired infrastructure.
- Office and Home Networks: Suits environments requiring simultaneous connections for multiple high-demand devices.
- Last-Mile Connectivity: Effective as a final bridge between a larger network and end-users.
Chateau is a high-speed, dual-band home access point that adapts to your needs. It features a powerful quad- core ARM CPU, a fast, reliable, and responsive CAT6 LTE modem for excellent mobile connectivity, and the most advanced networking software on the market – RouterOS. But don’t worry – it can be as simple or as complex as you want. Chateau is designed to serve the most diverse user groups: IT professionals can push it to its limits, regular households can plug it in and forget it exists. With Chateau, you will always have options.
Compared to the regular Chateau LTE6, this version features a supercharged quad-core ARM CPU running at 1.8 GHz. It can handle even the most complex tasks without breaking a sweat. You can run complex firewall rules, provide encrypted VPN tunnels for an entire office, run the most demanding container apps right on your router, and more! The addition of 2.5 Gigabit Ethernet gives you even more options. You can use the ultra- fast port to connect extra devices – like a home media server – or use it as your primary ISP connection while keeping the LTE modem for backup.
Remove the bottleneck in your mobile setup
Do you dream of escaping the hustle and bustle of the city and moving to the countryside? Perhaps you’ve already made the move but are frustrated by the slow internet speeds. Fear not, because Chateau is here to solve all your connectivity problems.
Many rural households are limited by cheap, featureless LTE routers that simply can’t handle the demands of modern internet usage. That’s where Chateau comes in. When the leading mobile operator in Latvia – LMT – replaced their previous client routers with Chateau devices, customer satisfaction went through the roof! Same LTE towers, same data plans, and a brand new Chateau – just like that! What is the point of having brand new phones, excellent LTE coverage, high-end laptops, and so on… if your old router is the bottleneck?
That’s right – wireless signal is now stronger than ever. Due to the Gen 6 802.11ax standard, we’ve seen up to 40% higher speed in the 5 GHz spectrum and up to 90% higher speed in the 2.4 GHz spectrum.
The freedom of LTE
Reach consistent speeds of up to 300 Mbps with carrier aggregation, as CAT6 allows devices to use multiple bands simultaneously. That is a huge advantage in areas with many LTE users. Chateau LTE6 provides better responsiveness in a crowded environment and higher efficiency for weaker signal situations in the countryside. Depending on the service provider, we have seen Internet speed doubling in rural areas after switching to carrier aggregation, so there is no need to wait for cable network expansions.
Ethernet test results
S53UG+5HaxD2HaxD-TC&FG621-EA | IPQ-6010 All port test | ||||||
Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Bridging | none (fast path) | 219.2 | 2662 | 593.5 | 2430.9 | 1509.2 | 821 |
Bridging | 25 bridge filter rules | 218.1 | 2649.1 | 460.3 | 1885.3 | 468.5 | 254.9 |
Routing | none (fast path) | 218.9 | 2657.8 | 596.6 | 2443.6 | 1228.3 | 668.2 |
Routing | 25 simple queues | 218.5 | 2653.5 | 463.4 | 1898 | 468.5 | 254.9 |
Routing | 25 ip filter rules | 215.3 | 2614.4 | 279.6 | 1145.2 | 281.8 | 153.3 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
IPsec test results
S53UG+5HaxD2HaxD-TC&FG621-EA | IPQ-6010 IPsec throughput | ||||||
Mode | Configuration | 1400 byte | 512 byte | 64 byte | |||
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Single tunnel | AES-128-CBC + SHA1 | 78.4 | 878.1 | 91.9 | 376.4 | 93.6 | 47.9 |
256 tunnels | AES-128-CBC + SHA1 | 50.1 | 561.1 | 55.5 | 227.3 | 58.6 | 30 |
256 tunnels | AES-128-CBC + SHA256 | 50 | 560 | 55.4 | 226.9 | 58.6 | 30 |
256 tunnels | AES-256-CBC + SHA1 | 49.4 | 553.3 | 54.8 | 224.5 | 58.6 | 30 |
256 tunnels | AES-256-CBC + SHA256 | 49.4 | 553.3 | 55 | 225.3 | 58.6 | 30 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
Brand | |
---|---|
MODEL |
Chateau LTE6 ax ,S53UG+5HaxD2HaxD-TC&FG621-EA |
Details | |
---|---|
Product code | S53UG+5HaxD2HaxD-TC&FG621-EA |
Architecture | ARM 64bit |
CPU | IPQ-6010 |
CPU core count | 4 |
CPU nominal frequency | auto MHz |
Switch chip model | IPQ-6010 |
RouterOS license | 4 |
Operating System | RouterOS v7 |
Size of RAM | 1 GB |
Storage size | 128 MB |
Storage type | NAND |
MTBF | Approximately 200'000 hours at 25C |
Tested ambient temperature | -40°C to 70°C |
IPsec hardware acceleration | Yes |
Suggested price | $199.00 |
Wireless capabilities
Details | |
---|---|
Wireless 2.4 GHz Max data rate | 574 Mbit/s |
Wireless 2.4 GHz number of chains | 2 |
Wireless 2.4 GHz standards | 802.11b/g/n/ax |
Antenna gain dBi for 2.4 GHz | 2 |
Wireless 2.4 GHz chip model | QCN-5022 |
Wireless 2.4 GHz generation | Wi-Fi 6 |
Wireless 5 GHz Max data rate | 1200 Mbit/s |
Wireless 5 GHz number of chains | 2 |
Wireless 5 GHz standards | 802.11a/n/ac/ax |
Antenna gain dBi for 5 GHz | 4 |
Wireless 5 GHz chip model | QCN-5052 |
Wireless 5 GHz generation | Wi-Fi 6 |
WiFi speed | AX1800 |
Mobile
Details | |
---|---|
3G Category | R8 (42.2Mbps Downlink, 11.2Mbps Uplink) |
3G bands | 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) |
LTE Category | 6 (300Mbit/s Downlink, 50Mbit/s Uplink) |
MIMO DL | 2x2 |
MIMO UL | 1x1 |
LTE FDD bands | 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz) |
LTE TDD bands | 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz) |
TAC | 86335904 |
Ethernet
Details | |
---|---|
10/100/1000 Ethernet ports | 4 |
Number of 2.5G Ethernet ports | 1 |
Peripherals
Details | |
---|---|
Number of SIM slots | 1 Modem (Micro SIM) |
Number of USB ports | 1 |
USB Power Reset | Yes |
USB slot type | USB type A |
Max USB current (A) | 1 |
Powering
Details | |
---|---|
Number of DC inputs | 1 (DC jack) |
DC jack input Voltage | 12-28 V |
Max power consumption | 17 W |
Max power consumption without attachments | 13 W |
Cooling type | Passive |
Certification & Approvals
Details | |
---|---|
Certification | CE, EAC, ROHS |
IP | 20 |
Other
Details | |
---|---|
PCB temperature monitor | Yes |
Voltage Monitor | Yes |
Mode button | Yes |
Wireless specifications
2.4 GHz | Transmit (dBm) | Receive Sensitivity |
---|---|---|
1MBit/s | -100 | |
11MBit/s | -94 | |
6MBit/s | 24 | -96 |
54MBit/s | 21 | -80 |
MCS0 | 24 | -96 |
MCS7 | 20 | -75 |
MCS9 | 19 | -70 |
MCS11 | 17 | -67 |
5 GHz | Transmit (dBm) | Receive Sensitivity |
---|---|---|
6MBit/s | 24 | -96 |
54MBit/s | 21 | -80 |
MCS0 | 24 | -96 |
MCS7 | 20 | -75 |
MCS9 | 19 | -70 |
MCS11 | 17 | -67 |
