NETAC BASIC DDR3 U-DIMM MEMORY 8GB Key Features
Power Supply: VDD=1.5V (1.425V to 1.575V)
VDDQ = 1.5V (1.425V to 1.575V)
800MHz fCK for 1600Mb/sec/pin
8 independent internal bank
Programmable CAS Latency: 11, 10, 9, 8, 7, 6
Programmable Additive Latency: 0, CL – 2, or CL – 1 clock
8-bit pre-fetch
Burst Length: 8 (Interleave without any limit, sequential with starting address “000” only), 4 with tCCD = 4 which does
not allow seamless read or write [either on the fly using A12 or MRS]
Bi-directional Differential Data Strobe
Internal (self) calibration; Internal self calibration through ZQ pin (RZQ: 240 ohm ± 1%)
On Die Termination using ODT pin
Average Refresh Period 7.8us at lower than TCASE 85°C, 3.9us at 85°C < TCASE < 95°C
Asynchronous Reset
Adjustable data-output drive strength
Fly-by topology
PCB : Height 1.18” (30mm)
RoHS Compliant and Halogen-Free
NETAC BASIC DDR3 U-DIMM MEMORY 8GB is a type of system memory designed primarily for desktop computers and entry-level workstations. It utilizes the third-generation Double Data Rate (DDR3) SDRAM technology, which offers improved speed and efficiency over its predecessor, DDR2. With typical data transfer rates ranging from 1066 MHz to 1600 MHz (and higher in some models), DDR3 U-DIMM provides faster performance and better multitasking capability for everyday computing tasks.
NETAC BASIC DDR3 U-DIMM MEMORY 8GB are Unbuffered memory, unlike registered or buffered modules, communicates directly with the system memory controller. This makes it ideal for home and office PCs that don’t require the additional stability and complexity of server-grade RAM. DDR3 U-DIMM modules usually come with 240 pins and operate at a standard voltage of 1.5V or a lower 1.35V for DDR3L variants, offering modest power savings.
These modules are easy to install and are widely compatible with most DDR3-enabled motherboards. Available in various capacities, commonly 2GB, 4GB, and 8GB per module, DDR3 U-DIMM memory allows users to expand their system’s RAM affordably. Though newer standards like DDR4 and DDR5 are now common, DDR3 U-DIMM remains a reliable and cost-effective solution for upgrading older desktop systems.
