Cisco Business CBS350-12XT 12-Port 10G Managed Network Switch – Ultimate Performance & Secure Connectivity for Growing Enterprises | Cisco

The Cisco Business CBS350-12XT is a high-performance managed network switch designed for small to medium-sized businesses seeking enterprise-level networking capabilities. The Cisco Business CBS350-12XT features 12 ports with high-speed 10 Gigabit Ethernet connectivity, including 10 x 10GBase-T RJ45 ports and 2 x 10G SFP+/RJ45 combo ports, making it versatile for connecting various wired devices such as computers and network storage.

We are trying hard to provide best price, still not satisfied. Let us know


    Please prove you are human by selecting the car.

    • Pick up from the FGTECH Store

    To pick up today

    0-1 Days

    Free

    • Courier delivery

    Our courier will deliver to the specified address

    4-7 Days

    Free

    • Porter / WeFast

    Currently available only in Mumbai

    0-1 Days

    To be paid directly to service vendor

    • Fast Delivery ( By Air )

    We will ship from your product By Air to nearest center to speed up the delivery

    2-4 Days

    Start from Rs250 Extra

    SKU: FGINH9ZF7X36 Categories: , Brand:
    Description

    The Cisco Business CBS350-12XT Managed Switch offers exceptional speed, reliability, and scalability for modern business networks. Built with an 800 MHz ARM processor, 512 MB of RAM, and 256 MB of flash memory, The Cisco Business CBS350-12XT supports a switching capacity of 240 Gbps and a forwarding rate of 178.56 million packets per second (Mpps). This ensures smooth data flow even in bandwidth-intensive environments.

    Designed for ease of management, the CBS350-12XT integrates seamlessly with the Cisco Business Dashboard portal and mobile app, allowing centralized monitoring and configuration. The Cisco Business CBS350-12XT true stacking capability supports up to four units with 200 ports managed as a single system, providing robust scalability and simplified network administration. The Cisco Business CBS350-12XT switch ensures high availability with fast stack failover and link aggregation support.

    Featuring comprehensive Layer 2 and Layer 3 functions, the Cisco Business CBS350-12XT supports secure connectivity, advanced traffic segmentation, and multicast protocols including IGMP and MLD versions. It includes support for multiple VLANs (up to 4094), ACL rules, and advanced routing protocols such as static IPv4/IPv6 and policy-based routing for flexible traffic management.

    With energy-efficient dual fans, a low noise profile, and an MTBF (mean time between failures) of over 633,000 hours, this rack-mountable switch is reliable and built to last. It supports key security features like 802.1x authentication, DHCP snooping, access control, and storm control mechanisms that protect against various network threats. The inclusion of USB and console ports facilitates easy configuration and updates.

    Ideal for unified communications and hybrid work environments, The Cisco Business CBS350-12XT switch delivers optimized performance for voice, video, and data traffic integration. Its compatibility with Cisco’s portfolio of IP telephony and business products makes it an excellent choice for growing enterprises looking for scalable, secure, and manageable 10G infrastructure.

    Technical Key Features

    • 12 ports including 10 x 10GBase-T RJ45 ports and 2 x 10G SFP+/RJ45 combo ports

    • Switching capacity: 240 Gbps; Forwarding performance: 178.56 Mpps

    • Processor: 800 MHz ARM CPU; Memory: 512 MB RAM; Flash: 256 MB

    • Supports up to 4094 VLANs and 1024 ACL rules

    • True stacking capability with up to 4 units and 200 managed ports

    • Layer 2 and Layer 3 features: RPVST+, MSTP, static IPv4/IPv6 routing, IGMP, MLD, PBR

    • Secure management protocols: SNMPv3, SSH, RADIUS, TACACS+

    • Advanced security: 802.1x authentication, DHCP snooping, IP source guard, storm control

    • Dual fans for quiet, efficient cooling

    • Rack-mountable with dimensions 440 x 203 x 44 mm

    • MTBF: 633,324 hours

    • Power: Internal supply 100-240V AC; power consumption approx. 64W

    • Management via Cisco Business Dashboard portal and mobile app

    • USB type-A port and RJ45 console port for easy management

    Product Details

    Specification CategoryDetails
    ManufacturerCisco
    Product NameCisco CBS350-12XT 12-Port 10G Managed Network Switch
    Model NumberCBS350-12XT-NA-RF
    Product TypeNetworking Switch
    Enclosure TypeRack-mountable
    Ports10 x 10GBase-T RJ45 ports, 2 x 10G SFP+/RJ45 combo ports
    Switching Capacity240 Gbps
    Forwarding Rate178.56 million packets per second (Mpps)
    MAC Address Table Size16,000 entries
    VLAN SupportUp to 4094 VLANs
    Jumbo Frame Support2 KB
    Max Units in Stack4 units
    Routing ProtocolsIGMPv2, IGMPv3, static IPv4/IPv6 routing, policy-based routing (PBR), MLDv2, CIDR, MSTP, RSTP, STP
    Management ProtocolsSNMP v1/v2c/v3, RMON, Telnet, HTTP/HTTPS, TFTP, SSH, CLI, SCP, DHCP, TACACS+, RADIUS
    AuthenticationSecure Shell (SSH), RADIUS, TACACS, TACACS+, SSH v2
    EncryptionSSL
    FeaturesFlow control, BOOTP, ARP support, VLANs, DoS prevention, DiffServ, Storm Control, IPv6, Quality of Service (QoS), DHCP snooping, Dynamic ARP Inspection, STP Root Guard, LACP, LLDP, DHCP relay, MIB, Multicast VLAN Registration, 802.1x authentication, IP source guard, Private VLAN Edge, LLDP-MED, IP/MAC/Port Binding, loopback detection, BPDU Guard, Voice Services Discovery Protocol, Rapid PVST+, etc.
    Standards ComplianceIEEE 802.3, 802.3u, 802.3z, 802.1D, 802.1Q, 802.3ab, 802.1p, 802.3x, 802.3ad, 802.1w, 802.1x, 802.3ae, 802.1s, 802.1ab, 802.3an, 802.3az
    ProcessorARM CPU, 800 MHz
    RAM512 MB
    Flash Memory256 MB
    Interfaces12 x 10GBase-T RJ-45, 2 x 10GBase-X SFP+, 1 x USB Type A, 1 x Gigabit LAN management RJ-45 console
    Power SupplyInternal, AC 100-240V, 50/60 Hz
    Power ConsumptionApprox. 63.9 to 64.1 Watts
    Operating Temperature0°C to 50°C (32°F to 122°F)
    Storage Temperature-25°C to 70°C (-13°F to 158°F)
    Humidity10% to 90% non-condensing
    Dimensions (W x D x H)440 mm x 203 mm x 44 mm (17.3 in x 8 in x 1.7 in)
    WeightApprox. 2.93 kg (6.46 lbs)
    MTBF633,324 hours
    Management SoftwareCisco Business Dashboard Web portal and mobile app
    Warranty & SupportLimited lifetime replacement warranty, 1 year technical support (web and phone)
    Special FeaturesHardware stacking up to 4 units with fast failover and link aggregation across stack, quiet operation with dual fan design, USB port for file management, comprehensive Layer 2 and Layer 3 features, optimized for unified communications
