The Cisco Catalyst C9200CX-12P-2X2G is a compact, fanless enterprise switch offering 12 Gigabit PoE+ ports with a 240W power budget and dual 10G SFP+ uplinks. The Cisco Catalyst C9200CX-12P-2X2G delivers robust Layer 2/3 switching, advanced security with AES-256 MACsec encryption, and seamless integration with Cisco DNA Center for smart network management. Ideal for quiet branch offices and scalable enterprise environments, this switch provides reliable, high-performance connectivity and power efficiency in a sleek form factor.
Pick up from the FGTECH Store To pick up today
0-1 Days
Free
Courier delivery Our courier will deliver to the specified address
4-7 Days
Free
Porter / WeFast Currently available only in Mumbai
0-1 Days
To be paid directly to service vendor
Fast Delivery ( By Air ) We will ship from your product By Air to nearest center to speed up the delivery
2-4 Days
Start from Rs250 Extra
The Cisco Catalyst C9200CX-12P-2X2G switch is designed to bring enterprise-class performance and reliability in a compact footprint. Unlike consumer-grade models such as Asus networking gear, this Cisco switch is tailored for professional IT environments where security, uptime, and power efficiency are paramount. Featuring 12 Gigabit Ethernet PoE+ ports capable of delivering up to 240W total power, it supports IEEE 802.3at and optional Cisco UPOE, enabling connectivity for a broad range of PoE-powered devices including IP phones, cameras, and wireless access points. The device stands out with its fanless design, ensuring silent operation and low power consumption, making it ideal for quiet office and branch location deployments.
The Cisco Catalyst C9200CX-12P-2X2G model includes dual 10G SFP+ uplink ports plus two fixed 1G Ethernet ports for flexible, high-speed aggregation and network expansion. Powered by Cisco’s IOS XE software platform, the switch offers advanced automation capabilities, API-driven provisioning, and support for Cisco DNA Center and Meraki cloud management dashboards. The Catalyst C9200CX-12P-2X2G leverages hardware-accelerated routing protocols (OSPF, EIGRP, RIP, and BGP basics) and supports AES-256 MACsec encryption, delivering robust network security and segmentation features. With a mean time between failures exceeding 700,000 hours and backed by Cisco’s limited lifetime warranty and support services, this switch provides enterprise-grade resiliency and longevity.
12 ports Gigabit Ethernet with PoE+ delivering up to 240W total power budget
Dual 10G SFP+ uplinks plus 2x 1G Ethernet fixed uplink ports for versatile connectivity
Fanless, silent operation with internal 315W AC power supply
Supports Layer 2 and Layer 3 features including OSPF, EIGRP, RIP, and basic BGP routing
Cisco IOS XE software with automation, programmability over NETCONF/RESTCONF, and SD-Access policy-based segmentation
Hardware security with AES-256 MACsec encryption and Cisco Trust Anchor technologies
Simplified cloud and on-premises management via Cisco DNA Center and Meraki dashboard
Power saving with Energy Efficient Ethernet (EEE) and dynamic PoE power allocation
Supports up to 16 virtual networks, 32,000 MAC address table entries, and 4,000 IPv4 routing entries
Compact form factor suitable for branch offices, retail, and quiet environments
High reliability with MTBF over 700,000 hours
| Specification Category | Details |
|---|---|
| Model Name | Cisco Catalyst C9200CX-12P-2X2G |
| Switch Type | Compact enterprise Layer 2/3 managed switch |
| Downlink Ports | 12 x 1G Ethernet PoE+ ports |
| Uplink Ports | 2 x 10G SFP+ fixed uplinks + 2 x 1G copper ports |
| PoE Power Budget | 240W total PoE+ power |
| Power Supply | Internal 315W AC power supply |
| Fan | Fanless silent operation |
| Layer 3 Routing Support | Static routing, OSPF, EIGRP, RIP, ISIS, Basic BGP (from IOS XE 17.13.1) |
| Encryption Support | AES-256 MACsec network encryption |
| Stacking Capability | No stacking support |
| Virtual Networks (VNs) | Supports up to 16 Virtual Networks |
| MAC Address Table Size | 32,000 MAC addresses |
| IPv4 Routing Entries | 14,000 total (10,000 direct + 4,000 indirect) |
| IPv6 Routing Entries | 2,000 |
| ACL Scale | 1,600 entries |
| QoS Scale | 1,000 scale entries |
| Switching Capacity | 68 Gbps |
| Forwarding Rate | 50.59 Million packets per second (Mpps) |
| Memory | 4 GB DRAM, 8 GB Flash |
| Dimensions (HxWxD) | 1.73" x 10.6" x 9.6" (4.4 cm x 26.9 cm x 24.4 cm) |
| Weight | 6.6 lbs (2.99 kg) |
| Operating Temperature Range | -5°C to 45°C (up to 5000 ft elevation) |
| Management Options | Cisco IOS XE CLI, Cisco DNA Center, Meraki Dashboard, WebUI |
| Power Efficiency | ENERGY STAR certified, Energy Efficient Ethernet (EEE) |
| Additional Features | Plug and Play, Precision Time Protocol (IEEE 1588v2), Bluetooth management interface |
| IEEE Standards Supported | IEEE 802.1s, 802.1w, 802.1x, 802.1Q VLAN, 802.3az, 802.3at, 802.3bt class 6, 10G Ethernet (802.3ae) |
