CP PLUS CP-UNC-TT41L3-VMD-Q Powerful 4MP IR AI Enforcement Camera with Motorized 10-50mm Lens & 140dB WDR

CP Plus CP-UNC-TT41L3-VMD-Q is a 4MP IR AI Enforcement Camera with motorized 10-50mm lens, 140dB WDR, ANPR, and IP67 weatherproof design for advanced vehicle monitoring.

Pick up from the FGTECH Store

To pick up today

0-1 Days

Courier delivery

Our courier will deliver to the specified address

4-7 Days

Porter / WeFast

Currently available only in Mumbai

0-1 Days

To be paid directly to service vendor

Fast Delivery ( By Air )

We will ship from your product By Air to nearest center to speed up the delivery

2-4 Days

Start from Rs250 Extra

SKU: FGIN1SB68R31 Categories: IP Cameras, Surveillance and Security Brand: CP Plus

Description

The CP Plus CP-UNC-TT41L3-VMD-Q is a high-performance 4MP IR AI Enforcement Camera designed for advanced vehicle monitoring and automatic number plate recognition (ANPR) applications. Equipped with a cutting-edge 1/1.8″ 4MP CMOS sensor, CP PLUS CP-UNC-TT41L3-VMD-Q camera delivers crystal-clear images at a maximum resolution of 2688 x 1520 pixels at 30 fps, ensuring accurate identification of vehicle details even under challenging lighting conditions.

The CP PLUS CP-UNC-TT41L3-VMD-Q motorized vari-focal lens with a wide focal length range of 10 to 50 mm and a bright aperture of F1.2 allows flexible zooming for distant or close-up views. With a remarkable 140 dB wide dynamic range (WDR) and advanced IR illumination up to 30 meters with four adjustable IR LEDs, the camera supports day and night operation with ICR auto-switch for sharp images around the clock.

CP PLUS CP-UNC-TT41L3-VMD-Q model supports multiple video compression formats, including H.265 and H.264 variants, enabling efficient bandwidth and storage usage. The CP PLUS CP-UNC-TT41L3-VMD-Q features sophisticated AI-powered analytics such as vehicle type, logo, and color recognition, helmet detection, speed and lane violations, and traffic flow monitoring.

Key Technical Features

1/1.8″ 4MP CMOS sensor, 2688 x 1520 @ 30fps resolution
Motorized vari-focal lens: 10–50mm with F1.2 aperture
140dB Wide Dynamic Range (WDR) for superior image clarity
Four adjustable IR LEDs with 30m night vision range
AI analytics: ANPR, vehicle type and color recognition, helmet detection, traffic violation capture
Video compression: H.265, H.264 (M/H/B), MJPEG
Cybersecurity: AES 256-bit, HTTPS, IP/MAC filtering, trusted boot
Weatherproof: IP67, Vandal-resistant IK10
Multiple connectivity options: Ethernet RJ45, RS-232, RS-485, GPS, PoE
Supports Micro SD storage up to 512GB, SFTP, NAS support
Operating temperature: –40 °C to +65 °C
Dimensions: 466.4 × 135.8 × 134.1 mm; Weight: 3.9 kg
Compliant with ISO9001, CE, FCC, BIS certifications

Product Details

Specification	Details
Model	CP-UNC-TT41L3-VMD-Q
Image Sensor	1/1.8" 4 MP CMOS (1.411 cm)
Effective Pixels	2688 (H) × 1520 (V)
Minimum Illumination	0.0001 Lux
Shutter Speed	Auto/Manual 1/50 s–1/100,000 s
White Balance	Auto, Manual, Outdoor, Natural, Street Lamp, Partial
Lens Type	Motorized vari-focal
Max Aperture	Max F1.2
Lens	10 mm–50 mm
Video Compression	H.265, H.264M, H.264H, H.264B, MJPEG
Back Light Compensation	BLC, HLC, WDR (140 dB)
Signal-to-Noise Ratio	>56 dB
Angle of View	Horizontal: 10°–44°, Vertical: 6°–24°, Diagonal: 12°–51°
Resolution	4MP (2688 × 1520), 2MP, UXGA, 720p, D1, CIF
Frame Rate	4MP @ 30fps (Main), UXGA @ 30fps (Sub)
Noise Reduction	2D NR, 3D NR
IR LED	4 IR LEDs (850 nm), 30 m range
Day/Night Mode	ICR Auto switch IR cut filter with polarizing filter
Protocols Supported	SFTP, IPv6, IPv4, DNS, RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profiles S/G/T), unicast, multicast
Bit Rate	H.264: 32 kbps–32767 kbps, H.265: 32 kbps–32767 kbps, MJPEG: 512 kbps–32767 kbps
Exposure Mode	Auto, Manual
Speed Detection Range	0 km/h–180 km/h
SDK & API Support	Yes
Ethernet Port	1 × RJ-45, 10/100 Mbps
Security Features	AES 256-bit encryption, HTTPS, MAC binding, Network Access Control, Trusted Boot, Configuration Encryption
Alarm Events	Storage full/error, External alarm, IP conflict, illegal access, Network disconnection
Cyber Security	AES 256, Configuration encryption, Trusted execution, Digest, WSSE, Account lockout, Syslog, Video encryption, IP/MAC filtering, Trusted upgrade, Trusted boot
OSD	Camera title, Date & Time
Vehicle Violation Capture	Speeding, wrong-way driving, helmet detection, illegal lane change
Traffic Flow Detection	Vehicle flow, average speed, vehicle type, lane occupancy, queue length, road status
Positioning	GPS
Image Tampering Check	Watermark verification
Storage	SFTP, NAS, Micro SD Card (Max 512GB)
RS-485/RS-232 Ports	RS-485: 2 Ports (radar devices), RS-232: 2 Ports (debug, radar)
Weatherproof Standard	IP67 & IK10
Operating Temperature	–40 °C to +65 °C
Operating Humidity	10%-90% RH
Dimensions	466.4 mm × 135.8 mm × 134.1 mm
Weight	3900 g
Power Source	12–36 V DC, PoE
Power Consumption	≤13 W
Certifications	ISO9001, CE, FCC, BIS
