CP PLUS CP-UVR-0401E1-CV2 Powerful 4 Channel 1080N Digital Video Recorder with H.265, 1 SATA HDD Support up to 6TB

CP PLUS CP-UVR-0401E1-CV2 is a 4-channel 1080N DVR with H.265 compression, 6TB HDD support, multi-format auto-adapt, and mobile app control for seamless security monitoring.

We are trying hard to provide best price, still not satisfied. Let us know


    Please prove you are human by selecting the house.

    • Pick up from the FGTECH Store

    To pick up today

    0-1 Days

    Free

    • Courier delivery

    Our courier will deliver to the specified address

    4-7 Days

    Free

    • Porter / WeFast

    Currently available only in Mumbai

    0-1 Days

    To be paid directly to service vendor

    • Fast Delivery ( By Air )

    We will ship from your product By Air to nearest center to speed up the delivery

    2-4 Days

    Start from Rs250 Extra

    SKU: FGIN7JSY13JH Categories: , Brand:
    Description

    The CP PLUS CP-UVR-0401E1-CV2 is a powerful 4-channel 1080N Digital Video Recorder designed to elevate your surveillance experience. CP PLUS CP-UVR-0401E1-CV2 advanced DVR integrates H.265 video compression technology, offering superior image quality while optimising storage efficiency. Featuring a state-of-the-art 4K resolution processor, it captures every detail with remarkable clarity. The CP-UVR-0401E1-CV2 supports multiple video inputs, including HDCVI, AHD, TVI, CVBS, and IP signals, with up to 5 IP cameras supported at 2MP resolution.

    CP PLUS CP-UVR-0401E1-CV2 versatile DVR includes one SATA HDD interface supporting up to 6TB storage capacity, ideal for extensive recording needs. It offers simultaneous video output through HDMI and VGA ports, allowing multi-display setups. The embedded Linux OS provides a user-friendly GUI, and the unit is compatible with CP PLUS mobile apps iCMOB and gCMOB, enhancing remote surveillance control at your fingertips.

    The CP PLUS CP-UVR-0401E1-CV2 is built with UNI technology for auto signal adaptation, simplifying installation by automatically recognising video formats. CP PLUS CP-UVR-0401E1-CV2 model is also ONVIF compliant for broad compatibility with third-party devices. Suitable for applications ranging from public safety and city centers to educational institutions, this DVR delivers dependable performance in a compact form factor.

    Key Technical Features:

    • Supports 4 channels with 1080N resolution recording

    • H.265 video compression for bandwidth and storage efficiency

    • Auto-adapts signal type: CVI, TVI, AHD, CVBS

    • Supports up to 5 IP camera inputs, each up to 2MP

    • Maximum incoming bandwidth of 20Mbps

    • 1 SATA HDD port supporting up to 6TB storage

    • Dual USB 2.0 ports for backup and data transfer

    • HDMI and VGA simultaneous video output

    • Embedded Linux OS with intuitive GUI

    • Compatible with mobile apps: iCMOB, gCMOB

    • ONVIF compliant for third-party device support

    • RoHS, FC certified and compliant with strict security protocols

    The CP PLUS CP-UVR-0401E1-CV2 combines superior technology with robust security features, making it the ideal choice for reliable and scalable surveillance solutions.

    Product Details

    SpecificationDetails
    BrandCP PLUS
    ModelCP-UVR-0401E1-CV2
    Channels4 channels (BNC) + up to 5 IP camera inputs (up to 2MP)
    Video Resolution1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
    Video CompressionH.265, H.264, InstaStream
    Video InputHDCVI, AHD, TVI, CVBS, IP
    Max Incoming Bandwidth20 Mbps
    Audio Input/Output1 channel RCA each
    Storage1 SATA HDD up to 6TB
    USB Ports2 x USB 2.0
    Video Output1 HDMI, 1 VGA (simultaneous)
    Display Resolution Support1920x1080, 1280x1024, 1280x720, 1024x768
    Operating SystemEmbedded Linux
    Motion DetectionSupported
    Playback FunctionalityPlay, pause, stop, rewind, fast play, digital zoom
    Network Interface1 x RJ-45 100 Mbps
    Protocol SupportHTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, ONVIF 16.12
    Power SupplyDC 12V, 1.5A
    Power Consumption10W (without HDD)
    Operating Temperature-10°C to 45°C
    Storage Temperature-20°C to 70°C
    Operating Humidity10% to 90% RH
    Storage Humidity0% to 90% RH
    Dimensions (LxWxH)198 mm x 202.9 mm x 41.5 mm
    Weight0.55 kg (without HDD)
    ComplianceRoHS, FC, ONVIF
