CP PLUS CP-UNC-DA21L3B-LQ is a 2MP IP dome camera with dual-light illumination, built-in microphone and speaker, PoE support, and fixed 3.6 mm lens for indoor or outdoor surveillance use.
Pick up from the FGTECH Store To pick up today
0-1 Days
Free
Courier delivery Our courier will deliver to the specified address
4-7 Days
Free
Porter / WeFast Currently available only in Mumbai
0-1 Days
To be paid directly to service vendor
Fast Delivery ( By Air ) We will ship from your product By Air to nearest center to speed up the delivery
2-4 Days
Start from Rs250 Extra
The CP-UNC-DA21L3B-LQ is a 2-megapixel IP-based dome surveillance camera designed for fixed-angle monitoring in residential, commercial, and institutional environments. It uses a 1/2.7-inch PS CMOS image sensor to deliver Full HD 1920 × 1080 resolution video at up to 25/30 frames per second, providing consistent image clarity for general security observation.
This camera features dual-light illumination, combining infrared and warm white light, each rated up to 30 meters. The illumination mode automatically adapts based on scene conditions, enabling color imaging in low-light environments and monochrome imaging in complete darkness when required. True day/night functionality is achieved through an ICR mechanism, supported by DWDR, 3D noise reduction, and multiple back-light compensation modes.
Audio capability is integrated through a built-in microphone and built-in speaker, allowing audio recording and audio deterrence where legally permitted. Video compression is handled through Instastream with support for H.265, H.264, and related codecs, along with triple-stream output for flexible recording and monitoring configurations.
The fixed 3.6 mm lens provides a horizontal field of view of 86°, suitable for entrances, corridors, and open areas. Power can be supplied via PoE (802.3af) or 12 V DC. Network connectivity is provided through a wired RJ-45 Ethernet interface; wireless connectivity is not included.
The housing combines metal and plastic construction and carries an IP67 rating, allowing use in outdoor environments within the specified operating temperature range.
Fixed indoor or outdoor surveillance with wired networking
Installations requiring audio monitoring or deterrence
Locations needing dual-light visibility up to 30 m
PoE-based IP camera systems and ONVIF-compatible NVRs
Wi-Fi-only installations
Battery-powered or solar-powered setups
Pan-tilt-zoom (PTZ) monitoring requirements
• Product Type: IP Dome Camera
• Brand: CP PLUS
• Model: CP-UNC-DA21L3B-LQ
• Image Sensor: 1/2.7" 2MP PS CMOS Image Sensor (0.9407 centimeters)
• Effective Pixels: 1920 (H) × 1080 (V)
• Maximum Resolution: 2MP (1920 × 1080)
• Frame Rate (Main Stream): 1–25/30 fps @ 2MP
• Frame Rate (Sub Stream 1): 720P, D1, VGA, CIF @ specified frame rates
• Frame Rate (Sub Stream 2): D1, VGA, CIF @ specified frame rates
• Video Compression: Instastream, H.265, H.264, H.264H, H.264B, MJPEG (sub stream only)
• Stream Capability: Triple stream
• Day/Night Mode: Auto (ICR) / Color / B/W
• Minimum Illumination (Color): 0.001 lux @ F1.4 (30 IRE)
• Minimum Illumination (B/W): 0.0001 lux @ F1.4 (30 IRE)
• Minimum Illumination (IR): 0 lux (IR on)
• Wide Dynamic Range: DWDR
• Noise Reduction: 3D NR
• Back Light Compensation: BLC / HLC / DWDR
• Image Rotation: 0° / 90° / 180° / 270°
• S/N Ratio: >58 dB
• Digital Watermarking: Supported
• Lens Type: Fixed-focal
• Lens Focal Length: 3.6 mm
• Maximum Aperture: F1.4
• Lens Mount: M12
• Close Focus Distance: 1.1 m
• Angle of View (Horizontal): 86°
• Angle of View (Vertical): 46°
• Angle of View (Diagonal): 103°
• IR Range: 30 m
• Warm Light Range: 30 m
• IR LEDs: 1 IR LED
• Warm Light LEDs: 1 warm light
• Smart IR: Supported
• Smart Illumination: Supported
• IR Control: Auto / Manual
• Built-in Microphone: Supported
• Built-in Speaker: Supported
• Audio Compression: G.711a, G.711Mu, PCM, G.726
• Motion Detection: Supported (4 areas, rectangular)
• Intelligent Motion Detection (IMD): Human and vehicle classification
• Audio Detection: Supported
• Video Tampering Detection: Supported
• Smart Search: Supported (with Smart NVR)
• Ethernet: RJ-45 (10/100 Base-T)
• Wi-Fi: Not supported
• Bluetooth: Not supported
• Network Protocols: IPv4, IPv6, HTTP, HTTPS, TCP/IP, UDP, RTP, RTSP, FTP, SFTP, NTP, DNS, DHCP, PPPoE, SNMP v3, TLS 1.2, ONVIF (Profile S, G, T), unicast, multicast
• SDK / API: Supported
• Power Supply: 12 V DC / PoE (802.3af)
• Power Consumption (Basic): 1.8 W (12 V DC), 2.5 W (PoE)
• Power Consumption (Maximum): 8.5 W (12 V DC), 10 W (PoE)
• RAM: 128 MB
• ROM: 128 MB
• Weatherproof Rating: IP67
• Operating Temperature: –40 °C to +60 °C
• Operating Humidity: ≤95% RH, non-condensing
• Storage Temperature: –40 °C to +60 °C
• Storage Humidity: ≤95% RH, non-condensing
• Casing Material: Metal + Plastic
• Dimensions: 100.9 mm × 109.9 mm
• Weight: 320 g
• Certifications: ISO 9001:2015, ISO 20000-1:2018, CE, FCC, RoHS, BIS, STQC
• Browser Support: IE, Chrome, Firefox
• Video Standard: PAL / NTSC
• User / Host Limit: 6
• Bit Rate Control: CBR / VBR
• Bit Rate Range (H.265): 3 kbps–6144 kbps
• Bit Rate Range (H.264): 8 kbps–6144 kbps
