CP-UVR-1601L1B-4KI2 | 16 Analog + 16 IP | 4K-N AI DVR with Face Recognition, SMD Plus & 32-Ch IP Support

The CP-UVR-1601L1B-4KI2 is a powerful 4K-N AI DVR designed to deliver exceptional surveillance performance with advanced SMD Plus, Perimeter Protection, and Face Recognition. The CP-UVR-1601L1B-4KI2 also supports up to 32 IP cameras for maximum scalability and smart security.

Pick up from the FGTECH Store

To pick up today

0-1 Days

Courier delivery

Our courier will deliver to the specified address

4-7 Days

Porter / WeFast

Currently available only in Mumbai

0-1 Days

To be paid directly to service vendor

Fast Delivery ( By Air )

We will ship from your product By Air to nearest center to speed up the delivery

2-4 Days

Start from Rs250 Extra

SKU: FGINFPKKFS25 Categories: Surveillance and Security, DVR Brand: CP Plus

Description

The CP-UVR-1601L1B-4KI2 is a next-generation 4K-N Digital Video Recorder engineered for high-performance multi-channel surveillance. Supporting 16 analog channels + 16 additional IP channels (32 total), it brings exceptional flexibility for hybrid setups where both traditional coax cameras and advanced IP cameras are required.

Powered by AI capabilities, the DVR delivers Smart Motion Detection (SMD Plus) with human and vehicle classification across 16 channels, minimizing false alarms and ensuring meaningful alerts. It also includes Perimeter Protection on 2 channels and Face Recognition on 2 analog channels with support for up to 20,000 face images—making it a strong choice for enterprise premises, commercial spaces, and high-security environments.

With H.265 / Instastream compression, the DVR reduces bandwidth and storage consumption while maintaining sharp video quality. It supports resolutions up to 4K, dual display outputs (HDMI & VGA), 128 Mbps incoming bandwidth, and offers smooth live view/playback with multiple split views.

Remote monitoring is seamless with iCMOB, gCMOB, and KVMS Pro, enabling real-time streaming, playback, digital zoom, and multi-device management. The device further enhances user convenience through auto signal detection, secured password policy, 2 USB ports, and a large 10TB storage capacity.

Built with reliability, scalability, and enterprise-level AI, the CP-UVR-1601L1B-4KI2 ensures unmatched surveillance performance for homes, offices, commercial complexes, warehouses, and more.

Product Details

Feature	Specification
Processor	Embedded processor
Operating System	Embedded LINUX
Performance	2 channel, 10 IVS for each channel
Object Classification	Human/Vehicle secondary recognition for tripwire and intrusion
AI Search	Search by target classification (Human, Vehicle)
SMD Plus Performance	16 channels
SMD AI Search	Search by target classification (Human, Vehicle)
Video Compression	AI Instastream / Instastream / H.265 / H.264+ / H.264
Video Output	1 HDMI, 1 VGA
Video Display Split	1 / 4 / 8 / 9 / 16
Video Resolution (Analog)	4K, 6MP, 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF
HDMI Resolution	3840×2160, 1920×1080, 1280×1024, 1280×720
VGA Resolution	1920×1080, 1280×1024, 1280×720
OSD Information	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Face Recognition Performance	Max 12 face pictures/sec; 2 analog channels support face recognition
Stranger Mode	Detects unknown faces; manual similarity threshold setting
AI Face Search	Up to 8 target faces simultaneously; threshold adjustable
Face Database	Up to 10 databases, 20,000 total images; fields for name, gender, address, etc.
Database Application	Each database can be assigned to video channels independently
Trigger Events	Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Output, PTZ Activation
Analog Camera Input	16 channels, BNC
HDCVI Input	4K, 6MP, 5MP, 4MP, 1080P@25/30fps, 720P@50/60/25/30fps
AHD Input	4K, 5MP, 4MP, 3MP, 1080P@25/30fps, 720P@25/30fps
TVI Input	4K, 5MP, 4MP, 3MP, 1080P@25/30fps, 720P@25/30fps
CVBS Input	PAL / NTSC
IP Camera Input	16 + 16 channels (total 32), up to 8MP per channel
Audio In/Out	1/1, RCA
Two-Way Talk	Uses audio input/output (RCA)
Audio Compression	G.711A, G.711U, PCM
Sample Rate	8 kHz, 16-bit per channel
Audio Bit Rate	64 Kbps per channel
Main Stream	4K(1–7fps), 6MP(1–10fps), 5MP(1–12fps), 4K-N/4MP/3MP(1–15fps), 4M-N/1080P/720P/960H/D1/CIF(1–25/30fps)
Sub Stream	960H(1–15fps), D1/CIF(1–25/30fps)
Smart Phone Compatibility	iPhone, iPad, Android
Mobile Apps	iCMOB, gCMOB
CMS Software	KVMS Pro
Hard Disk	1 SATA port, up to 10TB capacity
USB Ports	2 (1 USB 2.0, 1 USB 3.0)
RS485 Port	1
Recording Modes	Manual, Schedule, Motion Detection, Alarm, Stop
Search Modes	Time/Date, Alarm, Motion, Exact (to the second)
Bit Rate	32 kbps–6144 kbps per channel
Playback	1/4/9/16 channels
Playback Controls	Play, Pause, Stop, Rewind, Fast/Slow Play, Next/Prev File/Camera, Digital Zoom
Backup Options	USB Device / Network
Record Interval	1–60 min (default 60 min); Pre-record: 1–30s; Post-record: 10–300s
Video Detection	Motion Detection (396 zones 22×18), Video Loss, Tampering, Diagnosis
Network Interface	1 RJ-45 port (1000 Mbps)
Max. User Access	128 users
Network Protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, InstaOn, IP Search, ONVIF 16.12, CGI
Power Supply	DC 12V / 3A
Power Consumption	<15W (without HDD)
Operating Temperature	-10°C to +55°C, 0–90% RH
Storage Temperature	-20°C to +70°C, 0–90% RH
Dimensions	325 × 257 × 55 mm
Weight	1.3 kg (without HDD)
Additional Features	Signal auto-adapt, Secured Password Policy (SPP), Add-on IP camera support, Smart Motion Detection (SMD Plus)
