HPE ION Aruba 1960 16-Port Switch | 8x 1G/10GBase-T + 4x 1G/2.5G PoE+ RJ-45 | 2x 10G SFP+ | 2x 1G/10G RJ-45 Uplinks | 116 Gbps Switching | 480W PoE Budget | Layer 2+ Static Routing

Original price was: ₹237,679.00.Current price is: ₹118,839.00. Inc. tax (₹100,711.02Exc. Tax)

Boost your network performance with the HPE ION Aruba 1960 16-Port Switch, featuring 8x 1G/10GBase-T, 4x 1G/2.5G PoE+ RJ-45, 2x 10G SFP+, and 2x 1G/10G uplink ports. Delivering 116 Gbps switching capacity, Layer 2+ static routing, and a 480W PoE budget, it’s the ideal high-speed, stackable solution for growing business networks.

Add to wishlist

Add to compare

Pick up from the FGTECH Store

To pick up today

0-1 Days

Free

Courier delivery

Our courier will deliver to the specified address

4-7 Days

Free

Porter / WeFast

Currently available only in Mumbai

0-1 Days

To be paid directly to service vendor

Fast Delivery ( By Air )

We will ship from your product By Air to nearest center to speed up the delivery

2-4 Days

Start from Rs250 Extra

SKU: FGINE449C43E Categories: Networking Devices, Network Switches, PoE Switches Brand: Aruba

Description

HPE ION Aruba 1960 16-Port Switch is designed for high-demand environments, the HPE ION Aruba 1960 16-Port Switch delivers enterprise-level performance in a compact, rack mountable form. HPE ION Aruba 1960 16-Port Switch comes with a mix of multi-gigabit and 10G ports, it’s ideal for growing businesses that need reliable, high-speed switching with room to scale.

This model includes 8x 1G/10GBase-T ports for ultra-fast server and storage connectivity, 4x 1G/2.5G PoE+ RJ-45 ports for powering devices such as access points and IP cameras, and 4x 10G uplink options—2x SFP+ and 2x 1G/10G RJ-45—to ensure maximum flexibility for fiber or copper backhaul.

HPE ION Aruba 1960 16-Port Switch comes with a 480W PoE+ power budget, the switch can power multiple devices simultaneously without the need for external power injectors. Backed by 116 Gbps switching capacity and Layer 2+ features including static routing, it streamlines traffic between VLANs while keeping configuration simple and efficient.

Manage the switch your way—through the Aruba Instant On mobile app, cloud-based portal, or local web GUI. And for growing networks, the switch supports stacking of up to four units, making it easy to scale as your business grows.

HPE ION Aruba 1960 16-Port Switch is built for performance, flexibility, and easy management, the Aruba 1960 Series is the perfect fit for modern workspaces, edge deployments, and high-performance teams.

Key Features

✅ 8x 1G/10GBase-T Ports – High-speed connections for servers and bandwidth-heavy devices
✅ 4x 1G/2.5G PoE+ RJ-45 Ports – Power access points, cameras, and phones with up to 480W PoE budget
✅ 2x 10G SFP+ Uplinks + 2x 1G/10G RJ-45 Uplinks – Flexible fiber or copper uplink options
✅ 480W Class 4 PoE+ Power Budget – Generously powers multiple PoE devices simultaneously
✅ 116 Gbps Switching Capacity – Supports high-throughput workloads with ease
✅ Layer 2+ with Static Routing – Simplified inter-VLAN routing for network segmentation
✅ Stackable Design – Easily scale by stacking up to 4 switches
✅ Cloud & Local Management – Instant On Cloud portal, mobile app, or web GUI
✅ Rackmount-Ready Form Factor – Standard 1U size for easy deployment in server rooms

About Aruba

Aruba Networking Products in India – High-Performance Enterprise Solutions

Aruba, a Hewlett Packard Enterprise (HPE) company, is a global leader in networking solutions, offering cutting-edge access points, switches, and network management solutions. Designed for businesses, enterprises, and service providers, Aruba’s networking products ensure secure, scalable, and high-performance connectivity.

At FGTech Store, we provide a wide range of Aruba networking solutions in India, helping businesses build robust and future-ready IT infrastructure. Whether you need Wi-Fi 6 access points, enterprise-grade switches, or cloud-managed networking, Aruba has the perfect solution.

Aruba Access Points – Secure & High-Speed Wireless Connectivity

Aruba’s Wi-Fi access points (APs) deliver fast, reliable, and secure wireless connectivity for businesses, campuses, and large enterprises. With support for Wi-Fi 6 and AI-driven optimization, Aruba APs ensure seamless connectivity in high-density environments.

Key Features of Aruba Access Points:

✅ Wi-Fi 6 (802.11ax) support – Faster speeds, lower latency, and improved efficiency.
✅ AI-powered optimization – Ensures better performance in high-density networks.
✅ Zero Trust Security – Advanced security features protect against cyber threats.
✅ Cloud and On-Premise Management – Aruba Central for cloud-based monitoring and control.
✅ Seamless Roaming & High Capacity – Ideal for enterprises, universities, and large-scale deployments.

List of Popular Aruba Instant On Access Points

AP21: Wi-Fi 6, Dual-Band 2x2 MIMO, 1.5 Gbps, 1x 1GbE, ideal for small businesses.
AP22: Wi-Fi 6, Dual-Band 2x2 MIMO, 1.7 Gbps, 1x 1GbE (PoE), great for high-density areas.
AP22D: Wi-Fi 6, Dual-Band 2x2 MIMO, 1.7 Gbps, 4x 1GbE (1x PoE-in, 3x downlink), ideal for hotels/offices.
AP25: Wi-Fi 6, Dual-Band 4x4 MIMO, 5.3 Gbps, 1x 2.5GbE (PoE), for high-performance environments.
AP27: Wi-Fi 6, Outdoor 2x2 MIMO, 1.7 Gbps, 1x 1GbE (PoE), weather-resistant for outdoor use.
AP32: Wi-Fi 6E, Tri-Band 2x2 MIMO, 3.9 Gbps, 1x 2.5GbE (PoE), supports 6GHz for future-ready deployments.

Aruba Network Switches – Reliable & Scalable Connectivity

Aruba’s enterprise-grade network switches offer scalability, security, and automation, making them ideal for businesses, data centers, and service providers. Whether you need a compact switch for a small office or a high-performance core switch, Aruba has the right solution.

Key Features of Aruba Switches:

✅ High-Speed Data Transfer – Supports 1G, 10G, 25G, 40G, and 100G Ethernet.
✅ Smart Management – AI-driven automation and cloud-based Aruba Central integration.
✅ PoE+ and PoE++ Support – Power your Wi-Fi access points, IP cameras, and IoT devices.
✅ Advanced Security & SDN Support – Ideal for secure enterprise networking.
✅ Energy Efficient & Scalable – Low power consumption with seamless scalability.

Popular Aruba Switch Series:

🔹 Aruba Instant On 1930 Series – Best for small businesses and branch offices.
🔹 Aruba CX 6000 Series – Entry-level Layer 2 switches for enterprise networks.
🔹 Aruba CX 6100 & 6200 Series – Layer 2 & Layer 3 switches with cloud management.
🔹 Aruba CX 8325 & 8400 Series – Core switches for large-scale networks & data centers.

Why Buy Aruba Networking Products from FGTech Store?

At FGTech Store, we are committed to providing genuine Aruba networking products in India at competitive prices. Here’s why we are the best choice for your Aruba networking needs:

🔥 100% Genuine Aruba Products – We offer authentic Aruba switches, access points, and networking solutions with full manufacturer warranty.
🚀 Competitive Pricing – Get the best prices on Aruba networking products, including bulk purchase discounts.
⚡ Fast & Reliable Shipping – Nationwide delivery for quick deployment of Aruba solutions.
📞 Expert Technical Support – Our networking experts can help you choose the right Aruba products for your business.
🔧 Seamless Integration – Aruba products are designed to integrate easily into existing IT infrastructure.

Upgrade Your Network with Aruba – Shop Now at FGTech Store!

Boost your network performance, security, and reliability with Aruba’s cutting-edge networking products. Explore our range of Aruba access points, switches, and network solutions at FGTech Store and build a future-ready IT infrastructure today!

Order now and experience next-gen networking with Aruba!

Product Details

Core Specifications

Category	Details
Model Type	Managed Layer 2+ Stackable Switch
Form Factor	1U Rack-mountable
Total Ports	16 (4x 2.5G, 8x 1G/10G, 2x 1G/10G, 2x SFP+)
PoE Capability	480W Total Budget
MTBF	40.8 years

Port Configuration

Port Type	Quantity	Speed	PoE Support
RJ-45 2.5GBase-T	4	10/100/1000/2500	PoE+
RJ-45 10GBase-T	8	10/100/1000/10000	PoE++
RJ-45 Combo	2	10/100/1000	-
SFP+	2	1G/10G Fiber	-

Performance Metrics

Parameter	Specification
Switching Capacity	116 Gbps
Throughput	172 Mbps
Latency	1.8µs (1G), 2.8µs (10G), 6.7µs (2.5G)
Jumbo Frames	Up to 9216 bytes
MAC Address Table	16,000 entries

Power Specifications

Category	Details
Power Supply	Internal (100-240V AC)
PoE Budget	480W
Power Standards	IEEE 802.3af/at/bt
Efficiency	80 Plus Gold equivalent

Management & Security

Feature	Details
Management Protocols	SNMP v1/2c/3, HTTP/HTTPS, RADIUS
Security Features	TPM, ACL, 802.1X, Port Security
QoS	802.1p, DSCP, 8 queues per port
VLAN Support	802.1Q (4K VLANs), Voice VLAN

Physical Specifications

Category	Details
Dimensions (WxDxH)	17.4 x 13.8 x 1.7 in (44.2 x 35.1 x 4.3 cm)
Weight	11.55 lbs (5.24 kg)
Rack Units	1U

Environmental Specifications

Parameter	Operating	Storage
Temperature	32°F to 104°F (0°C to 40°C)	-40°F to 158°F (-40°C to 70°C)
Humidity	15-95% (non-condensing)	15-90% (non-condensing)

Certifications & Compliance

Standard	Certification
Safety	UL 62368-1, EN 60950-1
EMC	FCC Part 15 Class A, EN 55032 Class A
Environmental	RoHS, WEEE, Energy Star
Networking	IEEE 802.3 series, IPv6 Ready
