The Cisco Business CBS350-24NGP-4X 24-Port Multi-Gigabit PoE+ Managed Network Switch with 10G SFP+ & Combo Ports — a powerful Layer 3 switch built to provide scalable, high-speed connectivity and advanced network security for modern business environments. The Cisco Business CBS350-24NGP-4X 24- 24-port multi-gigabit PoE+ switch comes equipped with advanced Layer 3 features, ideal for powering and connecting next-generation devices like Wi-Fi 6/6E access points, IP cameras, VoIP phones, and high-performance workstations.
Pick up from the FGTECH Store To pick up today
0-1 Days
Free
Courier delivery Our courier will deliver to the specified address
4-7 Days
Free
Porter / WeFast Currently available only in Mumbai
0-1 Days
To be paid directly to service vendor
Fast Delivery ( By Air ) We will ship from your product By Air to nearest center to speed up the delivery
2-4 Days
Start from Rs250 Extra
The Cisco Business CBS350-24NGP-4X switch sets a new standard for small to medium business networks by delivering exceptional speed, flexibility, and power in one rack-mountable device. The Cisco Business CBS350-24NGP-4X Featuring 24 Multi-Gigabit Ethernet PoE+ ports supporting 1G/2.5G/5G speeds and a generous 375W PoE+ power budget, the Cisco Business CBS350-24NGP-4X switch simplifies deployment by enabling data and power delivery over a single cable. Four 10G SFP+ uplink ports and four combo ports provide ultra-fast fiber connectivity, offering seamless scalability and high-speed backbone integration essential for bandwidth-intensive applications.
The Cisco Business CBS350-24NGP-4X As a Layer 3 managed switch, the CBS350-24NGP-4X supports static IPv4 and IPv6 routing, enabling efficient traffic segmentation and dynamic routing capabilities necessary for growing networks. It supports up to four switches stacked together, allowing management of up to 96 ports from a single interface, which greatly simplifies network expansion and administration.
Security is comprehensive with features such as 802.1X authentication, Access Control Lists (ACLs), Denial of Service (DoS) prevention, DHCP snooping, and Secure Core Technology. Quality of Service (QoS) ensures optimal performance for latency-sensitive services like voice and video. Enhanced VLAN support permits up to 4094 VLANs to segregate and secure traffic efficiently.
Built with energy efficiency in mind, this switch operates quietly within a compact 1U form factor of 440 x 350 x 44 mm (17.3 x 13.78 x 1.73 in) ideal for rack mounting in enterprise environments. Cisco Business Dashboard and a user-friendly web interface provide intuitive management, minimising the need for dedicated IT staff. The Cisco Business CBS350-24NGP-4X device’s reliability, combined with Cisco’s global support and warranty, assures a future-proof investment for evolving business needs.
24 Multi-Gigabit Ethernet PoE+ ports supporting 1G/2.5G/5G speeds, up to 30W per port, total 375W PoE budget.
Four 10G SFP+ uplink ports for ultra-fast fiber connectivity.
Four combo ports with RJ-45 and SFP for flexible network expansion.
Layer 3 static routing, including IPv4/IPv6 support.
Switching capacity of 240 Gbps and forwarding rate of 178.57 Mpps for non-blocking performance.
True hardware stacking supporting up to 4 units (96 ports) with single system management.
Comprehensive security including 802.1X, ACLs, DoS mitigation, DHCP snooping, and Secure Core Technology.
Quality of Service (QoS) for prioritization of voice, video, and data traffic.
Support for up to 4094 VLANs for granular network segmentation.
Energy-efficient rack-mountable design with 1U form factor.
Extensive protocol support including Spanning Tree (STP, RSTP, MSTP), SNMP, LLDP, LACP, IGMP.
Robust memory specs: 512 MB RAM, 256 MB Flash, ARM 800 MHz processor.
Multiple management protocols: Web GUI, SNMP v1/2c/3, CLI, SSH, HTTP/HTTPS.
| Specification | Details |
|---|---|
| Product Name | Cisco CBS350-24NGP-4X |
| Brand | Cisco Systems |
| Model | CBS350-24NGP-4X |
| Device Type | Managed Layer 3 Switch |
| Number of Ports | 24 ports |
| Port Types | 16 x 10/100/1000 Mbps Ethernet PoE+ ports |
| 8 x 100/1000/2.5G/5G Ethernet PoE++ ports | |
| Uplink Ports | 2 x Combo 10 Gigabit SFP+/RJ-45 ports |
| 2 x 10 Gigabit SFP+ slots | |
| Power over Ethernet (PoE) | Supported |
| PoE Standard | Ultra PoE / PoE++ (Up to 60 Watts per port) |
| Maximum PoE Budget | 375 Watts |
| Switching Capacity | 192 Gbps |
| Forwarding Performance | 142.85 million packets per second (64-byte packets) |
| MAC Address Table Size | 16,000 entries |
| Jumbo Frame Support | Up to 2 KB |
| Packet Buffer Memory | 3 MB |
| VLANs Supported | Up to 4094 |
| Spanning Tree Protocols | Standard 802.1d, Rapid Spanning Tree 802.1w, MSTP 802.1s |
| Link Aggregation | IEEE 802.3ad LACP (up to 8 groups, 8 ports per group) |
| Routing Features | Layer 3 IPv4 and IPv6 routing, RIP v2, Static routes, CIDR |
| Routing Interfaces | Physical ports, Link Aggregation Group (LAG), VLAN interface, Loopback interface |
| Stacking | Hardware stacking up to 4 units, plug-and-play configuration |
| IPv6 Compatible | Yes |
| Dimensions (WxDxH) | 440 mm x 350 mm x 44 mm (17.32 x 13.78 x 1.73 inches) |
| Rack-mountable | Yes |
| Administration Level | Layer 3 management |
| SNMP Support | Yes |
| Physical Stack Limits | Up to 4 units with hardware failover |
