CP PLUS CP-UVR-0401E1-IC Powerful 4Ch-1080N Digital Video Recorder with H.265, 5 Channel IP Camera Support, 1 SATA HDD up to 6TB - Image 2

CP PLUS CP-UVR-0401E1-IC Powerful 4Ch-1080N Digital Video Recorder with H.265, 5 Channel IP Camera Support, 1 SATA HDD up to 6TB - Image 3

CP PLUS CP-UVR-0401E1-IC Powerful 4Ch-1080N Digital Video Recorder with H.265, 5 Channel IP Camera Support, 1 SATA HDD up to 6TB

CP PLUS CP-UVR-0401E1-IC is a 4-channel 1080N DVR with H.265 compression, 5 IP camera support, 6TB HDD capacity, HDMI/VGA output, and mobile app compatibility for advanced, secure surveillance solutions.

Pick up from the FGTECH Store

To pick up today

0-1 Days

Courier delivery

Our courier will deliver to the specified address

4-7 Days

Porter / WeFast

Currently available only in Mumbai

0-1 Days

To be paid directly to service vendor

Fast Delivery ( By Air )

We will ship from your product By Air to nearest center to speed up the delivery

2-4 Days

Start from Rs250 Extra

SKU: FGINRT4C82HS Categories: Surveillance and Security, DVR Brand: CP Plus

Description

The CP PLUS CP-UVR-0401E1-IC is a powerful 4-channel 1080N Digital Video Recorder designed for superior surveillance performance. This DVR integrates advanced 4K processing and H.265 dual-stream video compression technology to deliver crystal-clear images while optimising storage efficiently. The CP-UVR-0401E1-IC supports multiple video inputs, including HDCVI, AHD, TVI, CVBS, and IP, allowing seamless integration with diverse camera types. It accommodates up to 5 IP camera channels, each supporting video streams up to 2MP resolution with an incoming bandwidth of 20Mbps, making it adaptable to various security needs.

The CP PLUS CP-UVR-0401E1-IC model supports 1 SATA HDD up to 6TB for extensive storage and includes 2 USB ports for backup and external storage options. CP PLUS CP-UVR-0401E1-IC device features simultaneous HDMI and VGA outputs for flexible display configurations. Its intuitive shortcut operation menu and powerful Linux-based system enable remote management via mobile apps iCMOB and gCMOB or through the KVMS Pro CMS software, enhancing ease of use.

The CP PLUS CP-UVR-0401E1-IC stands out with its multi-signal UNI+ technology that auto-adapts to different video signal types, simplifying installation and system upgrades without additional manual adjustments. Strict password policies and robust security features ensure protection against hacking threats.

Key Features

Supports HDCVI, AHD, TVI, CVBS, and IP video input formats
Maximum 5 IP camera channels, each supporting up to 2MP resolution
Incoming bandwidth up to 20Mbps for smooth recording
Full-channel AI coding and H.265 dual-stream video compression for optimized storage
1 SATA HDD support, up to 6TB capacity
2 USB ports for easy data backup and transfer
Simultaneous HDMI and VGA video output support
Built-in Linux OS with intuitive shortcut operation menu
Multi-signal UNI+ technology auto-adapts to various video signals
Mobile support through iCMOB and gCMOB apps; KVMS Pro CMS for centralized management
Secured password policy requiring alphanumeric password changes
Wide-ranging applications in public safety, education, city centers, and more
RoHS, CE, FC, and ONVIF compliant

Product Details

Specification	Details
Model	CP-UVR-0401E1-IC
Brand	CP PLUS
Channels	4 Analog + 1 IP
Max IP Cameras Supported	5 (each up to 2MP)
Max Incoming Bandwidth	20 Mbps
Video Inputs	HDCVI, AHD, TVI, CVBS, IP
Video Outputs	1 HDMI, 1 VGA
Video Compression	H.265, H.264+, H.264, Instastream
Video Resolution	1080N, 720P, 960H, D1, CIF
Frame Rate	1~25/30 fps (Main Stream), 1~15 fps (Sub)
Hard Disk Drive	1 SATA port, up to 6TB
Audio Input/Output	1 RCA in/out
Operating System	Embedded Linux
Network Interface	1 RJ-45 (100Mbps)
USB Ports	2 x USB 2.0
Max User Access	128 users
Motion Detection	Yes (Human, Vehicle classification)
Alarm Inputs/Outputs	Supported
Power Supply	DC 12V/1.5A
Power Consumption	<7W (without HDD)
Operating Temperature	-10°C to +45°C
Dimensions (LxWxH)	198 mm x 203 mm x 41.5 mm
Weight	0.57 kg (without HDD)
Software Supports	iCMOB, gCMOB (Mobile), KVMS Pro (CMS)
Certifications	RoHS, CE, FCC, ONVIF compliant
