| Processor | Industrial-grade processor |
| IP Camera Input | 32 channel |
| Operating System | Embedded Linux |
| User Interface | Web, Local GUI |
| Video Output | 1× VGA, 1× HDMI; Heterogeneous video source output; Supports 4K display |
| Video Compression | H.265, Smart H.264+, H.264, MJPEG |
| Encode Strategy | Instastream |
| Decoding Capability | AI disabled: 2×32MP@20fps, 2×24MP@20fps, 4×16MP@30fps, 5×12MP@30fps, 8×8MP@30fps, 12×5MP@30fps, 16×4MP@30fps, 32×1080p@30fps AI enabled: 1×32MP@20fps, 1×24MP@20fps, 2×16MP@30fps, 4×12MP@30fps, 4×8MP@30fps, 8×5MP@30fps, 12×4MP@30fps, 24×1080p@30fps |
| AI by NVR | Face detection, Face recognition, Perimeter protection, SMD Plus |
| AI by Camera | Face detection, Face recognition, Video metadata, Perimeter protection, SMD Plus, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map |
| Resolution | 32MP, 24MP, 16MP, 12MP, 8MP, 5MP, 4MP, 1080p, 720p, D1, CIF, QCIF |
| Network Bandwidth | AI disabled: 384 Mbps incoming/recording/outgoing AI enabled: 200 Mbps incoming/recording/outgoing |
| Video Display Split | Main screen: 1/4/8/9/16/25/36 Sub screen: 1/4/8/9/16 |
| Perimeter Performance AI by NVR | 4 channels, 10 IVS rules per channel |
| Perimeter Performance AI by Camera | 16 channels |
| Face Attributes | Gender, Age group, Glasses, Expressions, Face mask, Beard |
| Face Detection Performance NVR | 2 channels, up to 12 face images/s each |
| Face Detection Performance Camera | 16 channels |
| Face Database Capacity | Up to 20 databases, 20,000 images, 2.5GB total |
| Face Recognition Performance NVR | 16-channel FD (camera)+FR (recorder): 16 images/s 2-channel FD+FR: 12 images/s |
| Face Recognition Performance Camera | 16 channels |
| SMD Plus NVR | 8 channels |
| SMD Plus Camera | 16 channels |
| Metadata Performance Camera | 8 channels |
| Human Attributes | Top color/type, Bottom color/type, Hat, Bag, Age, Gender, Umbrella |
| Motor Vehicle Attributes | License plate, color, body, model, logo, calling, seatbelt, interior, registration location |
| Non-motor Vehicle Attributes | Model, Color, Number of persons, Helmet |
| ANPR by Camera | 8 channels |
| License Plate Database Capacity | Up to 20,000 plate numbers; Blocklist and allow list |
| Intelligent Alarm | Face detection, Perimeter protection, Face recognition, Video metadata, SMD Plus, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map |
| Anomaly Alarm | Camera offline, Storage error, Disk full, IP/MAC conflict, Login lock, Fan abnormality, Cybersecurity exception |
| General Alarm | Motion detection, Privacy masking, Local alarm |
| Alarm Linkage | Record, Snapshot, Local/IPC external alarm output, Access controller, Audio, Buzzer, Log, Preset, Email |
| Audio Input | 1-channel RCA |
| Audio Output | 1-channel RCA |
| Audio Compression | G.711a, G.711u, PCM, G726 |
| Disk Group | Support |
| Alarm Input | 4 channels |
| Alarm Output | 2 channels (1×12V/1A) |
| Hard Disk | 2 SATA ports, up to 16TB each |
| Multi-channel Playback | Up to 16 channels |
| Record Mode | General, Motion detection, Intelligent, Alarm, POS |
| Browser | Chrome, IE9+, Firefox |
| Playback Mode | Instant, General, Event, Tag, Smart playback (face & motion detection) |
| Smart Phone | iPhone, iPad, Android |
| Backup Mode | USB Device/Network |
| Interface Ports | 2 USB (1 rear 3.0, 1 front 2.0), 1 RS232, 1 RS485 |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, InstaOn Cloud, Auto Registration, ONVIF 21.12, CGI, SDK |
| Ethernet | 1× 10/100/1000 Mbps RJ-45 |
| Power Supply | 12 VDC, 4A |
| Power Consumption | ≤10 W (without HDD) |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | 10%–93% RH |
| Storage Temperature | -20°C to +60°C |
| Dimensions | 375×284.4×56 mm |
| Weight | 1.57 kg (without HDD) |
