Lysora L6-T Wi-Fi 6 AX3000 Dual-Band Outdoor Access Point with 1GbE RJ45 Port, 4 Spatial Streams, 110+ Clients, PoE/PoE+

The Lysora L6-T Wi-Fi 6 AX3000 Dual-Band Outdoor Access Point supports IEEE 802.11 a/b/g/n/ac/ax standards and operates on the 2.4 GHz and 5 GHz bands. Lysora L6-T it provides throughput rates of up to 573 Mbps on 2.4 GHz and 2401 Mbps on 5 GHz, with 4 spatial streams and support for 110+ clients.

The L6-T offers a maximum coverage range of 300 m for 5 GHz and 100 m for 2.4 GHz, with recommended ranges of 200 m for 5 GHz and 50 m for 2.4 GHz, under the ideal conditions specified in the datasheet. Lysora L6-T it features 2 × 2 MU-MIMO on both 2.4 GHz and 5 GHz bands.

For wired connectivity, the access point provides 1 × 1GbE RJ45 port. It supports IEEE 802.3af PoE, IEEE 802.3at PoE+, and 24V passive PoE, with power consumption of ≤16 W. With IEEE 802.3af PoE, radio transmission and reception is limited to 2T2R at 2.4 GHz and 2T3R at 5 GHz, and the wireless rate at 5 GHz is 60% of the original rate.

Channel bandwidth supports 20/40 MHz on 2.4 GHz and 20/40/80/160 MHz on 5 GHz. Wireless features include Band Steering, Wireless Meshing, WMM, 802.1Q VLAN, RF Beamforming, Wi-Fi Speed Limiting, Client Device Isolation, and Wi-Fi Schedules. MLO and 4K-QAM are not supported. Roaming support includes 802.11v, 802.11k, 802.11r, Layer 2 roaming, and Layer 3 roaming.

The L6-T supports Router Mode and AP Mode, along with NAT, Static IP Address, DHCP Server, and PPPoE Dial-up. Security features include PSK Authentication, WPA, WPA2, WPA-PSK, OWE, WPA3-SAE, WPA2-PSK/WPA3-SAE, and 802.1X. Lysora L6-T it also supports AP Mesh Management, Captive Portal, and Bandwidth Limiting.

Management options include the Lysora App, Web Interface, Lysora Cloud, and SNMP. Up to 300 APs can be supported on a self-organizing network. The platform also supports optimization of Channel, Transmit Power, and Management Frame Power Settings, with both Pre-Optimization and Pro-Optimization settings displayed.

The access point supports wall and pole mounting, with mounts included. Its dimensions are 70 × 35 × 200 mm, and its weight is ≤0.4 kg without packaging materials. It operates from −30°C to +65°C, has an IP65 rating, and provides ±4 kV lightning/surge protection.

Key Features

• Wi-Fi 6 — Supports IEEE 802.11 a/b/g/n/ac/ax on 2.4 GHz and 5 GHz.
• AX3000 — Provides throughput rates up to 573 Mbps on 2.4 GHz and 2401 Mbps on 5 GHz.
• IP65 — Features IP65 weather resistance for outdoor deployment.
• 1GbE — Includes 1 × 1GbE RJ45 networking port.
• 300m Coverage — Provides a maximum 5 GHz coverage range of 300 m under ideal conditions.
• PoE+ — Supports IEEE 802.3af PoE, IEEE 802.3at PoE+, and 24V passive PoE.

Best Suited For

• Outdoor Wi-Fi 6 deployments
• Wall or pole-mounted installations
• Networks requiring a 1GbE RJ45 connection
• Deployments requiring IP65 protection
• Installations requiring coverage across the specified outdoor distances
• Networks using PoE, PoE+, or 24V passive PoE

Not Suited For

• Deployments requiring Wi-Fi 7 features
• Networks requiring MLO or 4K-QAM, as these are not supported
• Environments requiring an IP rating higher than IP65
• Operating conditions outside −30°C to +65°C
• Installations requiring a wired interface above 1GbE RJ45 based on the provided specifications
