MikroTik L009UiGS-2HaxD-IN | Powerful Dual-Band Router with SFP+ and Gigabit Ethernet for High-Speed Networking

Name: MikroTik L009UiGS-2HaxD-IN | Powerful Dual-Band Router with SFP+ and Gigabit Ethernet for High-Speed Networking - FGTECH STORE
SKU: FGIN72WY235F
Price: 12599.00 INR
Availability: InStock

SKU: FGIN72WY235F

MikroTik L009UiGS-2HaxD-IN is perfect for users who require both wireless and wired high-speed networking solutions. With its dual-band wireless support, fiber-optic connectivity via SFP+, and Gigabit Ethernet ports, this router offers a comprehensive networking solution for businesses, data centers, and advanced home users.

Original price was: ₹15,999.00.Current price is: ₹12,599.00. Inc. tax (₹10,677.12Exc. Tax)

MODEL	L009UiGS-2HaxD-IN L009UiGS-RM

Compare

Add to wishlist

Description

MikroTik L009UiGS-2HaxD-IN is a cutting-edge, high-performance router designed to meet the demands of modern networks. Offering dual-band connectivity, Gigabit Ethernet ports, and an SFP+ port, this router is ideal for both enterprise and advanced home networking environments, ensuring lightning-fast, reliable performance.

Key Features:

Dual-Band Wireless (2.4 GHz & 5 GHz): With support for both 2.4 GHz and 5 GHz frequencies, the L009UiGS-2HaxD-IN delivers exceptional wireless performance with reduced interference and optimal coverage.
SFP+ Port for Fiber Connectivity: The SFP+ port provides a high-speed, fiber-optic connection for long-distance, high-bandwidth networking, making it ideal for large-scale deployments and ISP-level setups.
4 Gigabit Ethernet Ports: With four Gigabit Ethernet ports, this router ensures ultra-fast wired connections for devices that require high-speed, stable networking.
Advanced CPU & RouterOS: Powered by a high-performance CPU and running on RouterOS Level 6, the L009UiGS-2HaxD-IN allows advanced configuration options such as routing, VPN, firewall management, and QoS to meet the needs of complex networks.
Rackmountable: Designed for professional IT environments, this router comes in a rackmountable form factor for easy integration into server rooms and data centers.
Optimized for High-Traffic Networks: Perfect for demanding applications, this router is capable of handling large volumes of traffic without compromising performance.

Here at MikroTik, we’re the world champions of server room tetris. So here’s our latest lifehack for the most efficient server rooms: grab an RB5009 with PoE-out ports. And mount it together with seven L009 routers in just two 1U rackmount spaces. You’ll become a living legend among system administrators, setting a new example of efficient space management and simple, reliable powering. And if you don’t need the wireless capability, you can cut costs even more and try the other version of this router: the L009UiGS-RM. It has all the same features – except for the 2.4 GHz wireless. And it comes with all the necessary mounting accessories.

RB2011 will always remain a networking legend, but it’s time to take it up a notch. And the L009 product line is the perfect upgrade that will help you save time, money, and server room space like never before.

Included parts

24V 1.5A power adapter

HGO indoor antenna kit

K-55 screw kit

Wireless specifications

2.4 GHz	Transmit (dBm)	Receive Sensitivity
1MBit/s	27	-100
11MBit/s	27	-94
6MBit/s	30	-96
54MBit/s	28	-80
MCS0	30	-96
MCS7	27	-75
MCS9	25	-70
MCS11	23	-67

Ethernet test results

L009UiGS-2HaxD-IN		IPQ-5018 all port test
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	282.6	3431.89	330.1	1352.09	324.1	176.31
Bridging	25 bridge filter	174.2	2115.48	178.4	730.73	181.8	98.90
Routing	None (fast path)	281.8	3422.18	309.9	1269.4	343.3	186.8
Routing	25 simple queues	143.2	1739.0	146.6	600.5	143.4	78.0
Routing	25 Filter rules	79.9	970.3	79	323.6	78	42.4

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544).
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes.
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results.

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.

Additional information

Weight	0.85 kg
Dimensions	32.5 × 13 × 5 cm
Badges	24Hr Dispatch

Product Details

Brand Name	Mikrotik
Model Name	Mikrotik L009UiGS-2HaxD-IN
Dimension(cm)	33X13X6
Weight(kg)	0.85

Product code	L009UiGS-2HaxD-IN
Architecture	ARM
CPU	IPQ-5018
CPU core count	2
CPU nominal frequency	800 MHz
Switch chip model	88E6190
RouterOS license	5
Operating System	RouterOS v7
Size of RAM	512 MB
Storage size	128 MB
Storage type	NAND
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-40°C to 70°C
Suggested price	$129.00

Wireless capabilities

Wireless 2.4 GHz Max data rate	574 Mbit/s
Wireless 2.4 GHz number of chains	2
Wireless 2.4 GHz standards	802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz	4
Wireless 2.4 GHz chip model	IPQ-5018
Wireless 2.4 GHz generation	Wi-Fi 6
WiFi speed	AX600

Ethernet

10/100/1000 Ethernet ports	8
Number of 1G Ethernet ports with PoE-out	1

Fiber

SFP ports

1 (2.5G supported)

Peripherals

Serial console port	RJ45
Number of USB ports	1
USB Power Reset	Yes
USB slot type	USB 3.0 type A
Max USB current (A)	1.5

Powering

Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	24-56 V
Max power consumption	47 W
Max power consumption without attachments	14 W
Cooling type	Passive
PoE in	802.3af/at
PoE in input Voltage	24-56 V

PoE-out

PoE-out ports	Ether8
PoE out	Passive PoE
Max out per port output (input 18-30 V)	1 A
Max out per port output (input 30-57 V)	450 mA
Max total out (A)	1.0 A

Certification & Approvals

Certification	CE, FCC, IC, EAC, ROHS
IP	20

Other

Mode button

Yes

Warranty & Manufacturer Details

Warranty Period	1 Year
Warranty Provider	Contact Fgtech Store for service warranty
Country of Origin	Lithuania
Manufacturer Details	SIA Mikrotlks, Unijas iela 2, Riga, LV-1039 LATVIA
Importer Details	Mikrotik India, Green Park, Delhi 110016
Packer Details	FGTECH INNOVATIONS LLP, Sakinaka, Andheri East, Mumbai 400072

Download Brochure

Brochure	Open
Quick Guide	Open
User Manual	Open
Block Diagram	Open
Dimensions	Open
SFP compatibility list	Open
RouterOS software manual	Open
Declaration of conformity	Open (CE)
FCC Grant of Certification (2.4GHz)	Open
RouterOS current release	routeros-7.14.3-arm.npk
RouterOS current release	wifi-qcom-7.14.3-arm.npk
