With netPower 15FR switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept – aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments.
You don’t have to worry about power options in the attic or the utility room – netPower 15FR has 15 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Ethernet port 15 can power other PoE capable devices with the same voltage as applied to the unit.
There are two SFP ports for fiber connectivity. The outdoor enclosure allows you to install this switch in all kinds of environments – from damp attics to elevator shafts and different poles with hose clamps. netPower 15FR – bringing the cost down and the speed up!
netPower 15FR has a non-blocking throughput of 3.6 Gbps, switching capacity of 7.2 Gbps and forwarding rate of 5.4 Mpps.
Switching results
CRS318-1Fi-15Fr-2S-OUT | |||||||
---|---|---|---|---|---|---|---|
Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Switching | Non blocking Layer 2 throughput | 292.6 | 3,553.2 | 845.9 | 3,464.7 | 5,357.1 | 2,742.9 |
Switching | Non blocking Layer 2 capacity | 292.6 | 7,106.4 | 845.9 | 6,929.3 | 5,357.1 | 5,485.7 |
Switching | Non blocking Layer 1 throughput | 292.6 | 3,600.0 | 845.9 | 3,600.0 | 5,357.1 | 3,600.0 |
Switching | Non blocking Layer 1 capacity | 292.6 | 7,200.0 | 845.9 | 7,200.0 | 5,357.1 | 7,200.0 |
Ethernet test results
CRS318-1Fi-15Fr-2S-OUT | 98DX3224 all port test | ||||||
Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Bridging | none (fast path) | 104.4 | 1267.8 | 199.4 | 816.7 | 169.4 | 86.7 |
Bridging | 25 bridge filter rules | 61.7 | 749.3 | 62.0 | 254.0 | 75.7 | 38.8 |
Routing | none (fast path) | 104.4 | 1267.8 | 117.8 | 482.5 | 138.3 | 70.8 |
Routing | 25 simple queues | 78.8 | 956.9 | 77.0 | 315.4 | 97.0 | 49.7 |
Routing | 25 ip filter rules | 44.7 | 542.8 | 45.1 | 184.7 | 52.4 | 26.8 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
