TP-Link VIGI C340S IP Camera – 4mm Lens

SKU: FGIN6VF1RJNP

VIGI 4MP Outdoor ColorPro Night Vision Bullet Network Camera

Original price was: ₹15,999.00.Current price is: ₹9,099.00. Inc. tax (7,711.02Exc. Tax)

Description

VIGI 4MP Outdoor ColorPro Night Vision Bullet Network Camera

  • Ultra-Low Light Color Night Vision: Capture 24-hour 4MP high-quality and colorful video even in ultra low-light conditions without any supplemental lights.
  • Face Recognition: Efficiently enhances access management and attendance control while better protecting privacy§.
  • People & Vehicle Analytics: Quickly find people and vehicles of interest using a series of attributes, allowing you to improve search efficiency§.
  • Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
  • Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly.
  • True WDR: Enable crystal-clear images in high contrast scenes.
  • Active Defense: Warn potential intruders instantly with sound and light when abnormal events.
  • Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere.
  • H.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk space.
  • IP67 Waterproof: Reliable IP67 for stable outdoor performance.
  • Flexible Management and Storage: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as onboard storage with SD card slot (up to 256GB).

TP-Link VIGI C340S IP Camera - 4mm Lens image 0

TP-Link VIGI C340S IP Camera - 4mm Lens image 1

VIGI ColorPro Night Vision

VIGI’s industry-leading ColorPro Night Vision technology enables its cameras to pierce the night and see everything in fine detail.
By adopting this best-in-class technology, VIGI C340S can provide 4MP high resolution and capture more vivid full-color images
in extreme low-light conditions.

Video: https://youtu.be/dt35zeXVjg0

Better than the Naked Eye

Featuring high low-light sensitivity, VIGI’s ColorPro Night Vision produces unparalleled colors along with amazingly crisp images in ultra-low light conditions, which can’t be achieved with natural eyesight.

TP-Link VIGI C340S IP Camera - 4mm Lens image 2

Beyond IR, Beyond Full-Color

Images captured by IR cameras or traditional full-color cameras will suffer from digital noise and the loss of detail. VIGI’s ColorPro Night Vision cameras reveal excellent image details even in extreme darkness.

TP-Link VIGI C340S IP Camera - 4mm Lens image 3

Less Light Pollution

Bright illumination is required by conventional full-color cameras to capture images at pitch-dark hours. But VIGI’s ColorPro Night Vision cameras delivers true color and bright imaging even in extremely low light with no spotlights needed, greatly reducing environmental light pollution.

TP-Link VIGI C340S IP Camera - 4mm Lens image 4

Core Technology

VIGI’s powerful ColorPro Night Vision ability to capture vivid images in extreme low-light conditions emerges from four breakthroughs:

TP-Link VIGI C340S IP Camera - 4mm Lens image 5

Human & Vehicle Classification

Integrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.

TP-Link VIGI C340S IP Camera - 4mm Lens image 6

Comprehensive AI Detection with Pre-Set Rules Supported

By setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.

TP-Link VIGI C340S IP Camera - 4mm Lens image 7

Set customized activity zones around key areas for more focused monitoring.

TP-Link VIGI C340S IP Camera - 4mm Lens image 8

Face Recognition

VIGI’s advanced built-in face recognition algorithm enables cameras to intelligently capture faces, extract facial features, and form unique facial data. By comparing the facial data with a face library, quickly match a human face, efficiently reducing the risk of unauthorized access.

TP-Link VIGI C340S IP Camera - 4mm Lens image 9

People & Vehicle Analytics

Quickly find people and vehicles of interest using a series of attributes.

TP-Link VIGI C340S IP Camera - 4mm Lens image 10

TP-Link VIGI C340S IP Camera - 4mm Lens image 11

Remote Management

Take full control over your security anytime and anywhere on the VIGI app or client.

TP-Link VIGI C340S IP Camera - 4mm Lens image 13

One system. Full security.

Run your business with peace of mind.

The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.

One system. Full security. Run your business with peace of mind. The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.

Product Details

Brand Name TP-Link
Model Name VIGI C340S
Dimension(cm) 28X13X14
Weight(kg) 0.93
CAMERA
Image Sensor 1/1.8” Progressive Scan CMOS
Shutter Speed 1/3 to 1/10000 s
Slow Shutter Yes
Minimum Illumination 0.0005 Lux; 0 Lux with white light
Day/Night Mechanism NA
Day/Night Switch Unified/ Scheduled/ Auto
LENS
Type Fixed Focal Lens
Focal Length 4 mm
Aperture F1.0
FOV 4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°
Lens Mount M16*P 0.5
DORI Distance 4 mm: Detect: 70 m (231 ft) Observe: 29 m (96 ft) Recognize: 14 m (46 ft) Identify: 7 m (23 ft)
ANGLE ADJUSTMENT (MANUAL)
Range Pan: -90° to 90° Tilt: -90° to 90°
ILLUMINATOR
IR LED N/A
White LED Quantity: 4 Range: 30m
Illuminator On/Off Control Auto/Scheduled/Always on/Always off
VIDEO
Max. Resolution 2688 x 1520
Main Stream Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 705x576, 640x480, 352x288, 320x240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Bit Rate Control CBR, VBR
Video Compression Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264
H.264 Type Main Profile/High Profile
H.264+ Main Stream Supported
H.265 Type Main Profile
H.265+ Main Stream Supported
Video Bit Rate Main Stream: 256 Kbps to 6 Mbps Sub-Stream: 64 Kbps to 512 Kbps
Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, HLC Adjustable by Client Software, Rotation (90°/270°)
Image Enhancement BLC/3D DNR/HLC
Wide Dynamic Range 120 dB
SNR ≥ 52 dB
Image Parameters Switch Yes
Privacy Mask Up to 4 Masks
ROI 1 Region
OSD Setting Yes
AUDIO
Audio Communication Two-Way Audio
Audio Input Yes
Audio Output Yes
Audio Compression Yes
Audio Sampling Rate 8KHz
Environment Noise Filtering Yes
Audio Bit Rate 64 Kbps(G.711 alaw)
NETWORK
Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
ONVIF Yes
API Open Network Video Interface (Profile S)
Simultaneous Live View 3 Main Streams & 3 Sub-Streams
Client VIGI App, VIGI Security Manager, Web UI
Web Browser Google Chrome® 57 and above Firefox® 52 and above Safari® 11 and above Microsoft® Edge 91 and above
Cloud Yes
Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
ALARM AND EVENT MANAGEMENT
Smart Event Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection, Scene Change Detection
Basic Event Motion Detection, Video Tampering Detection, Exception (Illegal Login), Scene Change Detection
Alarm Linkage Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Linkage Method N/A
Output Notification Message Push
DEEP LEARNING FUNCTION
People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.
Face Capture Support
Face Comparison Support
INTERFACES
Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm N/A
Reset Button Yes
Power DC Power Port
On-board Storage Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB
Built-in Microphone Yes; Records Anything Going on within a 15-ft Radius of the Camera
Built-in Speaker Yes
Audio N/A
GENERAL
Operating Temperature -30–60 °C
Storage Temperature -40–60 °C
Operating Humidity 95% or Less (Non-Condensing)
Storage Humidity 95% or Less (Non-Condensing)
Package Contents VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories
Materia Front Cover: Metal Back Cover: Plastic
Material Front Cover: Metal Back Cover: Plastic
Power Supply 12V DC ± 5%, Max. 10.1 W, 5.5mm Coaxial Power Plug PoE: 802.3af/at, class 0, Max. 11.5 W
Protection IP67
Product Dimensions (L x W x H) 102× 236× 99 mm
Certifications CE, NTRA, VCCI, KC, BSMI, FCC, IC

WARRANTY & MANUFACTURER DETAILS
Country of Origin China
Manufacturer Details TP-Link Corporation Limited, Kowloon, Hong Kong
Importer Details TP-Link India Private Limited, Palghar, Vasai, 401208
Packer Details TP-Link India Private Limited, Palghar, Vasai, 401208
