Ubiquiti PBE-5AC-620 PowerBeam AC 29dBI High-Performance airMAX Bridge
Experience superior long-range wireless performance with the Ubiquiti PBE-5AC-620 PowerBeam AC. Featuring a 620mm dish and airMAX AC technology, it ensures stable, high-speed connectivity for P2P and P2MP setups.
Original price was: ₹29,999.00.₹25,999.00Current price is: ₹25,999.00. Inc. tax (₹22,033.05Exc. Tax)
Out of stock
Out of stock
Description
Ubiquiti PBE-5AC-620 PowerBeam AC is a powerful airMAX bridge designed for long-range wireless connectivity. With a high-gain 620mm dish reflector and advanced technology, it ensures superior performance, stability, and throughput for demanding network environments.
5 GHz WiFi antenna with a 450+ Mbps Real TCP/IP throughput rate.
5 GHz, 25+ km link range- 450+ Mbps throughput
- Improved mounting
- Dedicated spectral analysis radio
- Dedicated WiFi management radio
5 GHz, 25+ km link range
450+ Mbps throughput
Improved mounting
Dedicated spectral analysis radio
Dedicated WiFi management radio
Ubiquiti PBE-5AC-620 combines advanced airMAX AC technology with a highly efficient antenna design to achieve unparalleled performance in demanding network environments. It supports speeds of up to 450 Mbps and operates in the 5 GHz spectrum, ensuring low-latency, high-throughput communication over vast distances. Whether you need to extend your network to remote locations or create a high-capacity wireless bridge, the PowerBeam AC has you covered.
Its robust 620mm dish improves beam directivity and noise immunity, ensuring reliable connections even in crowded RF environments. Installation is simple, with an intuitive design that reduces the need for additional tools. Built for outdoor durability, the PBE-5AC-620 is designed to withstand harsh weather conditions, offering stable performance in any climate.
The Ubiquiti PBE-5AC-620 stands out with its 620 mm antenna and 29 dBi gain, providing superior range and signal focus compared to the PBE-5AC-500 (500 mm, 27 dBi) and PBE-5AC-Gen2 (400 mm, 25 dBi). This makes it ideal for ultra-long-distance links or high-interference environments. However, the PBE-5AC-Gen2 offers advanced usability features like smartphone app support for easier alignment, which the 620 and 500 models lack.
Here’s a detailed comparison of the PBE-M5-400, PBE-5AC-Gen2, PBE-5AC-500, and Ubiquiti PBE-5AC-620:
| Feature | PBE-M5-400 | PBE-5AC-Gen2 | PBE-5AC-500 | PBE-5AC-620 |
|---|---|---|---|---|
| Wireless Protocol | airMAX M (802.11n) | airMAX AC (802.11ac) | airMAX AC (802.11ac) | airMAX AC (802.11ac) |
| Maximum Throughput | ~150 Mbps | ~450 Mbps | ~450 Mbps | ~450 Mbps |
| Antenna Size | 400 mm | 400 mm | 500 mm | 620 mm |
| Antenna Gain | 25 dBi | 25 dBi | 27 dBi | 29 dBi |
| Range | Up to 20-25 km | Up to 25-30 km | Up to 30-35 km | Up to 35+ km |
| Noise Immunity | Moderate | Superior | High | Very High |
| Ethernet Port | Gigabit Ethernet | Gigabit Ethernet | Gigabit Ethernet | Gigabit Ethernet |
| Management Interface | airOS M | airOS 8 with UNMS support | airOS 8 with UNMS support | airOS 8 with UNMS support |
| Smartphone App Support | No | Yes (WiFiman) | No | No |
| Channel Width | Up to 40 MHz | Up to 80 MHz | Up to 80 MHz | Up to 80 MHz |
| Surge Protection | Basic | Enhanced | Enhanced | Enhanced |
| PoE Support | Passive PoE (24V) | Passive PoE (24V) | Passive PoE (24V) | Passive PoE (24V) |
| Build Quality | Sturdy | Lightweight and compact | Larger and robust | Larger and robust |
| Use Cases | Medium-range links, cost-effective | Medium-range links, user-friendly setup | Long-distance links, reliable backhaul | Ultra-long-distance links, high-capacity backhaul |
| Price | Lower | Moderate | Higher | Highest |
| MODEL |
PBE-5AC-620 |
|---|
| Brand Name | Ubiquiti |
| Model Name | PBE-5AC-620 |
| Dimension(cm) | 74X74X25 |
| Weight(kg) | 10.34 |
| Mechanical | |
|---|---|
| Dimensions | 620 x 620 x 386 mm (24.4 x 24.4 x 15.2") |
| Weight | 6.4 kg (14.1 lb) |
| Enclosure material | Outdoor UV-stabilized plastic |
| Mounting | Pole mount kit (Included) |
| Wind loading | Without radome: 1510 N at 200 km/h (340 lbf at 125 mph) With radome: 1830 N at 200 km/h (411 lbf at 125 mph) |
| Wind survivability | 200 km/h (125 mph) |
| Hardware | |
| Networking interface | (1) GbE RJ45 port |
| Power method | Passive PoE 2-pair (4, 5+; 7, 8 return) |
| Power supply | 24V, 0.5A gigabit PoE adapter (Included) |
| Supported voltage range | 20-27V DC |
| Max. power consumption | 8.5W |
| ESD/EMP protection | Air/contact: ± 24 kV |
| LEDs | (1) Power, (1) LAN, (4) WLAN |
| Signal strength LEDs | Software-adjustable to correspond to custom RSSI levels |
| Salt fog test | IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5 |
| Vibration test | IEC 68-2-6 |
| Temperature shock test | IEC 68-2-14 |
| UV test | IEC 68-2-5 at 40° C (104° F) Equivalent: ETS 300 019-1-4 |
| Wind-driven rain test | ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5 |
| Ambient operating temperature | -40 to 70° C (-40 to 158° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | FCC, IC, CE, RoHS |
| System | |
| Gain | 29 dBi |
| Max. VSWR | 1.6:1 |
| Channel sizes | PtP Mode: 10/20/30/40/50/60/80 MHz PtMP Mode: 10/20/30/40 MHz |
| Polarization | Dual linear |
| Operating Frequency (Mhz) | |
| Worldwide | 5150 - 5875 MHz |
| USA U-NII-1 U-NII-2A U-NII-2C U-NII-3 | 5150 – 5250 MHz 5250 – 5350 MHz 5470 – 5725 MHz 5725 – 5850 MHz |
| Warranty Period | 1 Year |
| Warranty Provider | Contact Fgtech Store for service warranty |
| Country of Origin | China |
| Manufacturer Details | Ubiquiti Networks International Limited, 18/F Edinburgh Tower, The Landmark, Hong Kong |
| Importer Details | Rashi Peripherals Limited, Palghar, Maharashtra 401208 |
| Packer Details | Ubiquiti Networks International Limited |
