Mikrotik Hap Lite Tower RB941-2nD-TC

SKU: FGINUT59OHD3
Small home AP with four ethernet ports and a colorful enclosure.

Original price was: ₹4,999.00.Current price is: ₹2,499.00. Inc. tax (2,117.80Exc. Tax)

Payment Methods:

Description

Mikrotik Hap Lite Tower

The home Access Point lite (hAP lite) is an ideal little device for your apartment, house or office.

It supports button triggered WPS, for the convenience of not typing a complicated password when somebody wants to have wireless internet access, and can also be told to change to cAP mode and join a CAPsMAN centrally managed network by the push of a button.

Of course, the device runs RouterOS with all the features, bandwidth shaping, firewall, user access control and many others.

The hAP lite is equipped with a powerful 650MHz CPU, 32MB RAM, dual chain 2.4GHz onboard wireless, four Fast Ethernet ports and a RouterOS L4 license. USB power supply is included.

Included parts

5V 1A power adapter

Wireless specifications

2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 22 -96
11MBit/s 22 -89
6MBit/s 20 -93
54MBit/s 18 -74
MCS0 20 -93
MCS7 16 -71

Ethernet test results

RB941-2nD-TC QCA953x 100M four port test
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 32.5 394.7 93.9 384.6 430.2 220.3
Bridging 25 bridge filter rules 32.5 394.7 83.4 341.6 82.2 42.1
Routing none (fast path) 32.5 394.7 93.9 384.6 221.1 113.2
Routing 25 simple queues 32.5 394.7 93.9 384.6 118.7 60.8
Routing 25 ip filter rules 32.5 394.7 53.9 220.8 53.9 27.6
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.

Product Details

Brand Name Mikrotik
Model Name Hap Lite Tower RB941-2nD-TC
Dimension(cm) 19X13X6
Weight(kg) 0.27
Product code RB941-2nD-TC
Architecture SMIPS
CPU QCA9533
CPU core count 1
CPU nominal frequency 650 MHz
Switch chip model QCA9533-BL3A
RouterOS license 4
Operating System RouterOS
Size of RAM 32 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 100'000 hours at 25C
Tested ambient temperature -20°C to 70°C
Suggested price $24.95

Wireless capabilities

Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 1.5
Wireless 2.4 GHz chip model QCA9533
Wireless 2.4 GHz generation Wi-Fi 4

Ethernet

10/100 Ethernet ports 4

Powering

MicroUSB input Voltage 5 V
Number of DC inputs 1 (MicroUSB)
Max power consumption 3.5 W
Cooling type Passive

Certification & Approvals

Certification FCC, IC

Warranty & Manufacturer Details

Warranty Period 1 Year
Warranty Provider Contact Fgtech Store for service warranty
Country of Origin China
Manufacturer Details SIA Mikrotlks, Unijas iela 2, Riga, LV-1039 LATVIA
Importer Details Mikrotik India, Green Park, Delhi 110016
Packer Details FGTECH INNOVATIONS LLP, Sakinaka, Andheri East, Mumbai 400072

Download Brochure

Brochure Open
Quick Guide Open
User Manual Open
Block Diagram Open
RouterOS software manual Open
Declaration of conformity Open (CE)
FCC Grant of Certification (2.4GHz) Open
RouterOS current release Routeros-7.14.3-smips.npk
RouterOS current release wireless-7.14.3-smips.npk
