Ubiquiti UDM-Pro-Max Dream Machine Pro Max | High-Performance UniFi Cloud Gateway with 5 Gbps IPS and Redundant NVR Storage
The Ubiquiti Ubiquiti UDM-Pro-Max Max features 8x GbE, 2x 10G SFP+, and 2.5 GbE WAN ports. Powered by a Quad-core ARM CPU, 8GB DDR4 RAM, and 128GB SSD, it delivers advanced routing, VPN, and threat protection for enterprise networks.t
Original price was: ₹89,999.00.₹56,999.00Current price is: ₹56,999.00. Inc. tax (₹48,304.24Exc. Tax)
Description
Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE
Includes full UniFi application suite for device management
5 Gbps routing with IDS/IPS
(1) 10G SFP+*, (8) GbE RJ45 LAN ports
(1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
(2) 3.5″ NVR HDD bays with RAID data protection
Built-in 128 GB SSD for NVR detection recordings
UniFi Power Backup ready
1.3″ touchscreen
Ubiquiti UDM-Pro-Max is a high-performance network security appliance designed for enterprise-grade networking, routing, and security. With 8x GbE LAN ports, 1x 10G SFP+ LAN, 1x 2.5 GbE WAN, and 1x 10G SFP+ WAN, it provides seamless connectivity and multi-gigabit speeds.
Equipped with a Quad-core ARM Cortex-A57 processor, 8GB DDR4 RAM, and 128GB SSD storage, it ensures optimal performance for high-demand environments. The device supports redundant WAN failover, load balancing, and LTE backup to maintain uninterrupted internet access.
Advanced security features include signature-based IPS/IDS threat detection, application-aware firewall rules, and content filtering to safeguard sensitive data. The built-in VPN server supports WireGuard, OpenVPN, and IPsec protocols for secure remote access and site-to-site connections.
Ideal for businesses, the Ubiquiti UDM-Pro-Max offers license-free SD-WAN, QoS traffic prioritization, and customizable VLANs for efficient network management. It features a 1.3″ touchscreen display, 100W internal power supply, and a rugged aluminum and steel enclosure for durability.
Designed for scalability, it’s compatible with UniFi APs and UniFi Protect cameras, making it a versatile solution for networking, security, and surveillance.
IN THE BOX
DEPLOYMENT
BUILD FEATURES
| Badges |
24Hr Dispatch |
|---|---|
| Brand | |
| MODEL |
UDM-Pro-Max |
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Weight | 4.7 kg (10.4 lb) |
| Enclosure material | Aluminium CNC, SGCC steel |
| Mount material | SGCC steel |
| Hardware | |
| Processor | Quad-core ARM® Cortex®-A57 at 2.0 GHz |
| System memory | 8 GB DDR4 |
| On-board storage | 32 GB eMMC Integrated 128 GB SSD |
| Management interface | Ethernet Bluetooth |
| Networking interface | LAN: (8) GbE RJ45 ports (1) 10G SFP+ portWAN: (1) 2.5 GbE RJ45 port (1) 10G SFP+ port |
| IDS/IPS throughput | 5 Gbps* *Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation. |
| Power method | (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A |
| Power supply | AC/DC, internal, 100W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 100W |
| ESD/EMP protection | Air: ± 15kV, contact: ± 8kV |
| LCM display | (1) 1.3" touchscreen |
| Button | Factory reset |
| Ambient operating temperature | -10° to 40° C (14° to 104° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Gateway Features | |
| Performance | Redundant WAN with failover and load balancing WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Additional internet failover with LTE Backup Internet quality and outage reporting |
| Next-generation security | Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall |
| Advanced networking | License-free SD-WAN WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport and Identity VPN Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IGMP proxy IPv6 ISP support |
