Ubiquiti US-8-150W (130W) 8-Port Layer 2 PoE Switch

Name: Ubiquiti US-8-150W (130W) 8-Port Layer 2 PoE Switch - FGTECH STORE
SKU: FGINYH6EZ9G5

The Ubiquiti US-8-150W (130W) is an 8-port Layer 2 PoE switch with 2 SFP ports, 130W PoE budget, and 20 Gbps switching capacity. Designed for robust performance and centralized management via UniFi, it powers access points, cameras, and more with efficiency and reliability.

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

I have read and accept the Privacy policy

Add to wishlist

Compare

SKU: FGINYH6EZ9G5 Categories: Networking Devices, PoE Switches Brand: Ubiquiti

Description

The Ubiquiti US-8-150W (130W) is a powerful and versatile 8-port Layer 2 PoE switch designed to deliver robust network performance and efficient power management. Ubiquiti US-8-150W comes with 8 Gigabit Ethernet ports and 2 SFP ports, this switch provides seamless connectivity for high-speed data transfers, making it ideal for small to medium-sized networks.

Ubiquiti US-8-150W switch features 130W of total PoE budget, supporting IEEE 802.3af/at PoE+ and 24V passive PoE across its 8 ports, enabling it to power a wide range of PoE devices such as UniFi access points, IP cameras, and VoIP phones. It offers a non-blocking throughput of 10 Gbps and a switching capacity of 20 Gbps, ensuring consistent, lag-free performance even under heavy traffic.

Ubiquiti US-8-150W is housed in a durable SGCC steel enclosure, the US-8-150W is built for reliability and efficiency. It features advanced Layer 2 capabilities, including VLAN support, port mirroring, storm control, and more, making it suitable for business-grade deployments. With its internal 150W power supply and universal AC input, this switch is both compact and easy to deploy in diverse environments.

Integrated with the UniFi Network application, the US-8-150W enables centralized monitoring, configuration, and management for streamlined network control. Its efficient design, combined with a rich feature set, makes it an excellent choice for powering and managing devices in demanding network setups.

An 8-port, Layer 2 PoE switch with a fanless cooling system.

(8) GbE PoE+ ports*
(2) 1G SFP ports
130W total PoE availability

Product Details

Mechanical
Dimensions	235 x 43 x 204 mm (9.3 x 1.7 x 8")
Weight	1.7 kg (3.7 lb)
Enclosure material	SGCC steel
Hardware
Management interface	Ethernet In-Band
Networking interface	(8) GbE RJ45 ports (2) 1G SFP ports
PoE interface	(8) PoE/PoE+ 2-pair (Pins +1, 2; -3, 6) 24V DC/0.7A passive PoE 2-pair (Pins +4, 5; -7, 8)
Total non-blocking throughput	10 Gbps
Switching capacity	20 Gbps
Forwarding rate	14.88 Mpps
Power method	Universal input, 100—240V AC, 50/60 Hz
Power supply	AC/DC, internal, 150W
Max. power consumption	20W (Excluding PoE output) 150W (Including PoE output)
Total available PoE	130W
Max. PoE wattage per port by PSE	PoE: 17W PoE+: 34W
Voltage range PoE mode	24V passive PoE: 20–27V PoE+: 50—57V
ESD/EMP protection	Air/contact: ± 24kV
Button	Factory reset
Ambient operating temperature	-5 to 45° C (23 to 113° F)
Ambient operating humidity	5 to 95% noncondensing
Certifications	CE, FCC, IC
LEDs
Ethernet	PoE Speed/link/activity
