Hi-Focus HF-S08E2-120WH 8-Port PoE Switch – 8× 10/100Mbps PoE RJ45, 2× 10/100Mbps Uplink, 120W PoE Budget, IEEE 802.3af/at, 250m Long-Range Transmission, 6KV Lightning Protection

The Hi-Focus HF-S08E2-120WH 8-Port PoE Switch provides network connectivity through 8 × 10/100 Mbps PoE RJ45 ports on Ports 1–8 and 2 × 10/100 Mbps RJ45 ports on Ports 9–10. This configuration provides eight PoE ports along with two additional RJ45 ports.

The switch supports IEEE 802.3i, 802.3u, 802.3x, 802.3af, 802.3at, and 802.3bt network standards. Hi-Focus HF-S08E2-120WH 8-Port it provides 2.0 Gbps bandwidth, a 1.49 Mpps packet forwarding rate, and a 1K MAC table size.

For PoE applications, the switch provides a total 120 W PoE budget. Ports 1–6 support up to 30 W per port, while Ports 7–8 support up to 60 W per port. The PoE pin configuration is 1/2 (+), 3/6 (-).

The switch uses storage-and-forwarding technology and includes Power, LINK/ACT, and PoE LED indicators. All ports support 6KV lightning protection. Hi-Focus HF-S08E2-120WH 8-Port it has dimensions of 21 × 15.2 × 4 cm and supports an operating temperature range of 0°C to 40°C.

Key Features

• 8 × 10/100 Mbps PoE RJ45 ports with 2 × 10/100 Mbps RJ45 ports
• 120 W total PoE budget
• Up to 30 W per port on Ports 1–6 and 60 W per port on Ports 7–8
• 2.0 Gbps bandwidth and 1.49 Mpps forwarding rate
• 6KV lightning protection on all ports

Best Suited For

• Small and medium network installations requiring PoE connectivity
• Setups requiring up to 8 PoE ports
• Devices compatible with IEEE 802.3af/at/bt
• Installations requiring a 120 W PoE budget
• Networks requiring additional 10/100 Mbps RJ45 connectivity

Not Suited For

• Networks requiring Gigabit Ethernet ports
• Applications requiring more than 8 PoE ports
• Devices requiring PoE power beyond the 120 W budget
• Individual devices requiring more than 60 W on Ports 7–8
• Networks requiring uplink speeds above 10/100 Mbps
