hAP ax lite is the perfect tiny solution when you’ve got to cut costs but can’t afford to sacrifice performance. Our latest Gen6 AX wireless chip allows you to squeeze the traditional 2.4 GHz wireless spectrum like a lemon! Depending on your overall setup, you can expect an increase in speed of up to 90%!
Very useful in scalable setups like hotels or expanding offices – the appealing price point, compact size, and a strong set of features allows adding more devices without a doubt! And – speaking of hotels – why not pack a hAP ax lite for your vacation? It takes up almost no space in your suitcase and allows you to break free from the restrictive guest networks.
Our hAP lite devices have always been about value. With 256 MB of RAM , a modern ARM CPU running at 800 MHz, 4x Gigabit Ethernet ports , much higher dual-chain antenna gain (up to 4.3 dBi!), and a complete visual redesign, the new hAP ax lite is a real trailblazer of value and affordable networking.
Included parts
Wireless specifications
2.4 GHz | Transmit (dBm) | Receive Sensitivity |
---|---|---|
1MBit/s | 22 | -100 |
11MBit/s | 22 | -100 |
6MBit/s | 22 | -95 |
54MBit/s | 18 | -77 |
MCS0 | 22 | -95 |
MCS7 | 17 | -75 |
MCS9 | 16 | -69 |
MCS11 | 15 | -61 |
Ethernet test results
L41G-2axD | IPQ-5010 all port test | ||||||
Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Bridging | none (fast path) | 202.8 | 2462.8 | 373.2 | 1528.5 | 396.8 | 215.9 |
Bridging | 25 bridge filter rules | 173.9 | 2112.3 | 175.8 | 719.9 | 181.5 | 98.7 |
Routing | none (fast path) | 202.8 | 2462.8 | 321.1 | 1315.4 | 348.4 | 189.6 |
Routing | 25 simple queues | 137.4 | 1668.1 | 140.2 | 574.4 | 141.9 | 77.2 |
Routing | 25 ip filter rules | 77.9 | 946.5 | 75.8 | 310.5 | 76 | 41.3 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544).
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes.
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results.
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
