Mikrotik CCR2004-16G-2S+PC

SKU: FGIN994BXCRO

Up to 300% faster than the previous CCR1009 routers – in a blissful silence! Luxury you deserve for the price you can afford. 16x Gigabit Ethernet ports, 2x10G SFP+ cages.

Original price was: ₹56,999.00.Current price is: ₹39,500.00. Inc. tax (33,474.58Exc. Tax)

Payment Methods:

Description

Mikrotik CCR2004-16G-2S+PC image 0

Like the other models in CCR2004 series, this CCR also features the Amazon Annapurna Labs Alpine v2 CPU with 4x 64-bit ARMv8-A Cortex-A57 cores. While this CPU is running at 1.2 GHz, the router can be 3x as fast than the previous generation CCR’s. This is the silent powerhouse. Enjoy all the power of a real CCR in peace and quiet. Get rid of all the hum and buzz in your office, studio, server room or homelab without sacrificing the performance.

The new router has 18 wired ports, including 16x Gigabit Ethernet ports and two 10G SFP+ cages. It also has a RJ-45 console port on the front panel.

Each group of 8 Gigabit Ethernet ports is connected to a separate Marvell Amethyst family switch-chip. Each switch chip has a 10 Gbps full-duplex line connected to the CPU. The same goes for each SFP+ cage – a separate 10 Gbps full-duplex line. Boards come with 4GB of DDR4 RAM and 128MB of NAND storage.

So as you can see – no bottlenecks. As long as the CPU can handle the processing, all ports can reach wire speed. And this CPU is a beast that can handle a lot. If we look at the performance, you can see that it is trading blows with our CCR1009.

The best part? This brand new CCR is among the most affordable options out there – not only within the CCR series, but on the market in general. One of the most common ways to use this device would be: Gigabit Ethernet ports for the internal network; SFP+ ports for downlink and uplink. The perfect all-in-one solution for small and medium-sized businesses. Easy and efficient.

With the new CCR2004, you can take your office network to the next level. Without breaking the bank.

Included parts

Ears

48 V 0.95 A power adapter

K-83

Ethernet test results

CCR2004-16G-2S+PC AL32400 all port test (1200 MHz)
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 2650.7 32190.3 5715.4 23410.1 8079.9 4395.5
Bridging 25 bridge filter rules 1110.3 13483.8 1113.5 4560.9 1119 608.7
Routing none (fast path) 2573.6 31253.4 5061.1 20730.4 7226 3930.9
Routing 25 simple queues 1084.6 13171.6 1106.1 4530.4 1079.4 587.2
Routing 25 ip filter rules 668 8112.5 675.8 2767.9 683.9 372.1
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544).
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes.
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results.

IPsec test results

CCR2004-16G-2S+PC AL32400 IPsec throughput
Mode Configuration 1400 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Single tunnel AES-128-CBC + SHA1 203 2273.6 204.1 836 202.2 103.5
256 tunnels AES-128-CBC + SHA1 232.4 2602.9 230.5 944.1 222.2 113.8
256 tunnels AES-128-CBC + SHA256 232.4 2602.9 230.5 944.1 222.2 113.8
256 tunnels AES-256-CBC + SHA1 232.3 2601.8 227.3 931 238.1 121.9
256 tunnels AES-256-CBC + SHA256 232.3 2601.8 227.3 931 238.1 121.9
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544).
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes.
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results.
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
Product Details

Brand Name Mikrotik
Model Name Mikrotik CCR2004-16G-2S+PC
Dimension(cm) 40X23X15
Weight(kg) 1.47
Product code CCR2004-16G-2S+PC
Architecture ARM 64bit
CPU AL32400
CPU core count 4
CPU nominal frequency 1200 MHz
Switch chip model 88E6191
Dimensions 272 x 195 x 44 mm
RouterOS license 6
Operating System RouterOS v7
Size of RAM 4 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -20°C to 60°C
IPsec hardware acceleration Yes
Suggested price $465.00

Powering

Number of DC inputs 2 (DC jack, 2-pin terminal)
DC jack input Voltage 36-57 V
2-pin terminal input Voltage 36-57 V
Max power consumption 36 W
Max power consumption without attachments 30 W
Cooling type Passive

Ethernet

10/100/1000 Ethernet ports 16

Fiber

SFP+ ports 2

Peripherals

Serial console port RJ45

Other

CPU temperature monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes

Certification & Approvals

Certification CE, EAC, ROHS
IP IP 20

Warranty & Manufacturer Details

Warranty Period 1 Year
Warranty Provider Contact Fgtech Store for service warranty
Country of Origin Lithuania
Manufacturer Details SIA Mikrotlks, Unijas iela 2, Riga, LV-1039 LATVIA
Importer Details Mikrotik India, Green Park, Delhi 110016
Packer Details FGTECH INNOVATIONS LLP, Sakinaka, Andheri East, Mumbai 400072

Download Brochure

Brochure Open
Quick Guide Open
User Manual Open
RouterOS current release Download
Block Diagram Open
SFP compatibility list Open
RouterOS software manual Open
Declaration of conformity Open (CE)
