Mikrotik RB1100AHx4 Dude Edition | 1U rackmount router with 13x Gigabit Ethernet ports, 60GB M.2 drive for Dude database

SKU: FGINIKMH43GA

Warranty Period :- 1 Year

Powerful 1U rackmount router with 13x Gigabit Ethernet ports, 60GB M.2 drive for Dude database

Original price was: ₹49,999.00.Current price is: ₹46,200.00. Inc. tax (₹39,152.54Exc. Tax)

Out of stock

Out of stock

Compare
Add to wishlist

Description

New RB1100AHx4 Dude Edition has Annapurna Alpine AL21400 CPU with four Cortex A15 cores clocked at 1.4GHz each, for a maximum throughput of up to 7.5Gbps. The device supports IPsec hardware acceleration and is faster at it than any previous RouterBOARD device (up to 2.2Gbps with AES128).



Unit comes with 1U rackmount case, 13x Gigabit Ethernet ports, RS232 serial port and dual redundant power supplies (with -48v DC telecom power and 802.3at/af support). The RB1100AHx4 Dude edition features several high speed storage connectors (two SATA and two M.2) for using a Dude database, proxy cache or any other storage intensive feature. It includes a 60GB M.2 drive already installed.

Ethernet test results

RB1100Dx4 AL21400 1G all port test
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 606.5 7,365.3 1,736.4 7,112.3 5,509.7 2,821.0
Bridging 25 bridge filter rules 606.5 7,365.3 1,107.8 4,537.5 1,153.2 590.4
Routing none (fast path) 606.5 7,365.3 1,736.4 7,112.3 5092.3 2,607.3
Routing 25 simple queues 606.5 7,365.3 933.6 3,824.0 960.3 491.7
Routing 25 ip filter rules 543.7 6,602.7 561.8 2,301.1 564.6 289.1
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

IPsec test results

RB1100Dx4 AL21400 IPsec throughput
Mode Configuration 1400 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Single tunnel AES-128-CBC + SHA1 92.1 1031.5 93.1 381.3 92.3 47.3
256 tunnels AES-128-CBC + SHA1 115.5 1293.6 117.4 480.9 132.3 67.7
256 tunnels AES-128-CBC + SHA256 115.5 1293.6 117.4 480.9 132.3 67.7
256 tunnels AES-256-CBC + SHA1 114.6 1283.5 111.4 456.3 126.3 64.7
256 tunnels AES-256-CBC + SHA256 114.6 1283.5 111.4 456.3 126.3 64.7
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..



IN THE BOX

Additional information
Brand

Mikrotik
MODEL

RB1100AHx4 Dude Edition
Product Details

Details
Product code RB1100Dx4
Architecture ARM 32bit
CPU AL21400
CPU core count 4
CPU nominal frequency 1.4 GHz
Switch chip model RTL8367
Dimensions 443 x 148 x 44 mm
RouterOS license 6
Operating System RouterOS
Size of RAM 1 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 70°C
IPsec hardware acceleration Yes
Suggested price $385.00

Powering

Details
Number of AC inputs 2
Number of DC inputs 2 (2-pin terminal, PoE-IN)
2-pin terminal input Voltage -48, 20-57 V
Max power consumption 33 W
Max power consumption without attachments 25 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 20-57 V

Ethernet

Details
10/100/1000 Ethernet ports 13

Peripherals

Details
Extended storage 60GB M.2 SSD included
Memory card type microSD
Memory Cards 1
SATA ports 2x SATA3
Serial console port RS232
Number of M.2 slots 2

Other

Details
Current Monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Beeper Yes

Certification & Approvals

Details
Certification CE, EAC, ROHS
IP IP20
