TP-Link LS109P 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+, 63 W PoE Budget

SKU: FGINEPT3CHB9

The TP-Link LS109P is a 9-port desktop switch with 8 PoE+ ports, offering a 63W PoE budget. Perfect for powering IP cameras and access points, it provides 10/100Mbps speeds with a simple plug-and-play setup, ideal for small to medium-sized networks.


Original price was: ₹4,299.00.Current price is: ₹2,499.00. Inc. tax (2,117.80Exc. Tax)

Estimated shipping date: 09/12/2024 - 10/12/2024

Description

The TP-Link LS109P is a high-performance 9-port desktop switch, offering 8 PoE+ ports that provide both power and data to PoE-enabled devices such as IP cameras, access points, and VoIP phones. TP-Link LS109P comes With a total PoE power budget of 63W, this switch supports efficient, reliable performance for your small to medium-sized network. TP-Link LS109P its an plug-and-play design ensures easy setup, while its energy-efficient features help reduce operational costs. Perfect for businesses and offices looking for a cost-effective, reliable networking solution with Power over Ethernet capabilities.

  • 63 W PoE Budget: Eight 10/100 Mbps 802.3af/at-compliant PoE ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*
  • Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**
  • PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices.
  • Traffic Separation for Higher Security: Isolation Mode allows one-click client traffic separation to avoid snooping and tampering, and isolate broadcast storms.
  • Plug and Play: Simply plug and play for instant connectivity with no configuration required.
  • Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses.
  • Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments.





Ideal for IP Surveillance
—Up to 250 m Transmissions





Toggle for Network Security and Stability





Plug and Play



Additional information
Weight 0.88 kg
Dimensions 23 × 26 × 8 cm
Brand

MODEL

LS109P

Badges

24Hr Dispatch

Product Details

HARDWARE FEATURES
Interface • 9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ Ports) • AUTO Negotiation • AUTO MDI/MDIX
Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
Installation • Desktop • Wall Mounting
Power Supply External Power Adapter (Output: 53.5VDC / 1.31A)
PoE Ports (RJ45) • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8, up to 30 W PoE output per port • Power Supply: 63 W
LED Indicator • Power • Link/Act • PoE Status • PoE MAX
Dimensions ( W x D x H ) 6.7×3.9×1.1 in (171×98×27 mm)
Max Power Consumption • 3.67 W (220 V/50 Hz no PD connected) • 73.24 W (220 V/50 Hz with 63 W PD connected)
Max Heat Dissipation • 12.48 BTU/h (220 V/50 Hz no PD connected) • 249 BTU/h (220 V/50 Hz with 63 W PD connected)
PERFORMANCE
Switching Capacity 1.8 Gbps
Packet Forwarding Rate 1.3392 Mpps
MAC Address Table 2K
Jumbo Frame 1.5 KB
SOFTWARE FEATURES
Advanced Features • Extend Mode Button (Ports 1–4/1–8, Up to 250 m PoE power supply and data transmission) • Isolation Mode Button (Ports 1–8) • PoE Auto Recovery Button (Ports 1–8) • Compatible With IEEE 802.3af/at Compliant PDs • Mac Address Auto-Learning and Auto-Aging • IEEE 802.3x Flow Control • Green Technology
Transfer Method Store and Forward
OTHERS
Certification CE, FCC, RoHS
Package Contents • LS109P • Power Adapter • Installation Guide • Rubber Feet
Environment • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
