D-Link DGS-1210-52

SKU: FGINMGN71BO3

52-Port Gigabit Smart Managed Switch

Original price was: ₹48,999.00.Current price is: ₹33,719.00. Inc. tax (28,575.42Exc. Tax)

Payment Methods:

Description

DGS-1210-52

  • 48 x 10/100/1000BASE-T ports
  • 4 x Gigabit GbE/SFP combo ports
  • Advanced L2 switching and security features
  • L2+ Static Routing
  • Optional “standard mode” or “surveillance mode” management user interface

Powerful, yet Cost-Efficient

The D-Link DGS-1210 Series Smart Managed Switches are the latest generation of switches to provide increased Power over Ethernet (PoE) output, a range of physical interface types, multiple management interfaces, and advanced Layer 2 features. With all of these features combined, the DGS-1210 Series provides a cost-efficient and flexible solution for expanding any business network.

The DGS-1210 Series switches support 8, 24, or 48 10/100/1000BASE-T ports. Each switch also supports an additional 2 or 4 Gigabit SFP ports for optical connections using multimode or singlemode SFP transceivers.



PoE Support

Five of the nine models in the DGS-1210 series family support Power-over-Ethernet capabilities, simplifying deployments with IP cameras, VoIP phones, wireless access points, and other powered devices. These models include the DGS-1210-10P, DGS-1210-10MP, DGS-1210-28P, DGS-1210-28MP and DGS-1210-52MP. Using the switch’s management interface, an administrator can control various PoE functions, such as remotely rebooting cameras or access points, from anywhere on the network, including over the Internet.

They also support time-based PoE, which allows administrators to set a time window that determines when each port’s PoE power is turned on and off. All PoE models support the IEEE 802.3af and 802.3at standards, and each PoE power budget varies per model.

D-Link DGS-1210-52 image 0

Automatic Configuration

The DGS-1210 Series supports Auto Voice VLAN and Surveillance Mode, which allow voice and video traffic to be automatically identified and handled differently to regular network traffic. Auto Voice VLAN detects Voice over IP (VoIP) traffic and automatically segments it from the rest of the network, increasing security and allowing Quality of Service (QoS) to be applied.

Surveillance Mode detects compatible ONVIF cameras and places them in a surveillance VLAN, allowing a single switch to be used for voice, video, and data, removing the need for dedicated hardware and reducing maintenance costs. Surveillance Mode also includes its own Web UI, making surveillance features easily accessible and simplifying management of your surveillance network.

D-Link DGS-1210-52 image 1

Extensive Management and Layer 2 Features

The DGS-1210 Series comes equipped with a complete lineup of L2 features, including IGMP snooping, port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for fast, reliable data transfers.

The Series also supports advanced features such as static routing, which allows for communication between different user groups in different VLAN segments in a network. The switch can directly handle inter VLAN routing using multiple interfaces, making the network run faster and more efficiently. And, because the switches can manage internal routing, the network router can be assigned to handle external traffic routing only.

D-Link DGS-1210-52 image 2

Comprehensive Security Features

D-Link’s innovative Safeguard Engine helps protect switches against traffic flooding and virus attacks. 802.11X port-based authentication allows the network to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and helps to protect the internal IT network.
D-Link DGS-1210-52 image 3
Product Details

Brand Name D-Link
Model Name DGS-1210-52
Aggregation
8 x Link Aggregation Group Per Device 8 x Max Port Per Link Aggregation Group
Comply with RoHS 6
Yes
Console Port
Yes
CPU Speed
400MHz
DRAM Size
128 MB
Flash Memory Size
32 MB
IGMP Snooping
Max 1024 IGMP Snooping Groups
Operating Altitude
1500 m
Power Saving
By LED Shut-Off By Link Status By Port Shut-Off By System Hibernation
Spanning Tree Protocol (STP)
IEEE 802.1D STP IEEE 802.1s MSTP IEEE 802.1w RSTP
Control
802.3x Flow
Dimensions
440 x 210 x 44 mm
Energy Efficiency Ethernet (EEE)
Yes
Head-of-line (HOL) Blocking Prevention
Yes
Humidity
Operating: 0% - 95% RH Storage: 0% - 95% RH
Interfaces
4 x 1000M SFP 4 x Max IP Interface 4 x SFP ports 48 x 10/100/1000BASE-T ports 48 x 1000Base-T
Jumbo Frame
9,216 Bytes
MAC Address Table Size
16K
Maximum Forwarding Rate
77.4 Mpps
Maximum Heat Dissipation
132.08 BTU/hr
Maximum Power Consumption
38.35 W/240 V 38.85 W/100 V
MTBF
381,999 hours
Packet Buffer Size
3.0MB
Power Input
100 to 240 V AC
Standby Power Consumption
21.49 W/240V 21.72 W/100V
Store & Forwarding Forwading
Yes
Switching Capacity
104 Gbps
Temperature
Operating: -5 to 50° C (23 to 122° F) Storage -20 - 70°C
Weight
3.31 kg
WARRANTY & MANUFACTURER DETAILS
Warranty Period 3yrs
Warranty Provider Contact Nearest D-link Service Centre for warranty
Country of Origin Taiwan
Manufacturer Details No. 289, Sinhu 3rd Road, Neihu District, Taipei, 114
Importer Details D-link India , Andheri Mumbai, Maharashtra 400059
Packer Details D-link India , Andheri Mumbai, Maharashtra 400059
