D-Link DGS-F1026P-E

SKU: FGINMCE144M9

24GE PoE + 2 SFP Ports 250m PoE Switch

Original price was: ₹37,999.00.Current price is: ₹27,300.00. Inc. tax (23,135.59Exc. Tax)

Payment Methods:

Description

DGS-F1026P-E

  • 24 10/100/1000 Mbps gigabit ethernet ports
  • 2 SFP port
  • 250watts available PoE
  • Flow control for protection against loss data
  • Maximum distance of 250m
  • Light protection (6kV)
  • Operating Temperature: 0 to 40 deg C (32 to 104 deg F)



High Transmission distance

With high distance connectivity, ideal for surveillance solution. Can be used with cat5e or cat6 cable. The DGS-F1026P-E features 24 ports 10/100BASE-TX ports that support the IEEE 802.3af/at PoE protocol. With total power budget of 250W.

Plug & Play Installation

The DGS-F1026P-E is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. 802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.

Different Switch working mode

The DGS-F1026P-E switch works in 4 operating modes using DIP switch

  • Extend – 1-8 ports support up to 250m distance power supply
  • VLAN-Isolating ports 1-24 from each other can effectively suppress network storms and improve network performance
  • QoS-Prioritize the identified video data to make video transmission smoother
  • PoE-Automatic detection power of port, power off and restart

D-Link DGS-F1026P-E image 0

Product Details

Brand Name D-Link
Model Name DGS-F1026P-E
Size Desktop (with Mounting Kit)
Network Interface 24 10/100/1000 BASE-T ports, 2 SFP
Standards IEEE 802.3u, Fast Ethernet standards; IEEE 802.3af/at, Ethernet power supply POE standard; IEEE 802.3ab, Gigabit Ethernet standards; IEEE 802.3az, EEE, Energy efficient Ethernet standard; IEEE 802.3x, Full-duplex Ethernet data link layers ; IEEE 802.3z, Gigabit Ethernet fiber-optic standard
Media Interface Exchange Auto MDI/MDI-X adjustment on all ports
Lightning protection 6KV
Switching Fabric 52 Gbps
Transmission Method Adopt Store-and-forward
Data Transfer Rates Gigabit Ethernet -1000 Mbps, Ethernet -100 Mbps
Physical specifications Dimensions (LxWxH): 440 x 180 x 44mm, Weight: 3.0kg
POE Power Budget 250W (30 W max. per PoE port)
Power Total Power: 250W
Humidity Operating: 0% to 95% RH non-condensing, Storage: 0% to 95% RH non-condensing

WARRANTY & MANUFACTURER DETAILS
Warranty Period 3yrs
Warranty Provider Contact Nearest D-link Service Centre for warranty
Country of Origin Taiwan
Manufacturer Details No. 289, Sinhu 3rd Road, Neihu District, Taipei, 114
Importer Details D-link India , Andheri Mumbai, Maharashtra 400059
Packer Details D-link India , Andheri Mumbai, Maharashtra 400059
