TP-Link TL-SF1005P

SKU: FGIN8S3Y873U

5-Port 10/100Mbps Desktop Switch with 4-Port PoE+

Original price was: ₹4,999.00.Current price is: ₹2,350.00. Inc. tax (1,991.53Exc. Tax)

Payment Methods:

Description

  • 5× 10/100 Mbps RJ45 ports
  • 4× PoE+ ports transfer data and power on individual cables
  • Works with IEEE 802.3af/at compliant PDs
  • Supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 67 W for all PoE ports*
  • Up to 250m data and power transmitting range under Extend Mode**
  • Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
  • Plug and play with no configuration required

Video: Introducing TP-Link PoE Switches

TP-Link TL-SF1005P image 0

TP-Link TL-SF1005P image 1

Dedicated 4-Port PoE+ Switch (67 W Budget) for Numerous Applications

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 67 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

TP-Link TL-SF1005P image 2

Plug and Play, No Configuration Required

TP-Link TL-SF1005P image 3

Ideal for IP Surveillance—Up to 250 m Transmissions

With extend mode, the PoE transmission distance reaches up to 250 m*—perfect for IP Camera deployment in large areas.

*The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.

TP-Link TL-SF1005P image 4

Priority Video Quality Guaranteed

Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.

TP-Link TL-SF1005P image 5

Intelligent Power Management

When total power consumption exceeds 67 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

TP-Link TL-SF1005P image 6

TP-Link TL-SF1005P image 7



Product Details

Brand Name TP-Link
Model Name TL-SF1005P
Dimension(cm) 13X19X12
Weight(kg) 0.73
HARDWARE FEATURES
Interface 5× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af/at PoE+ ports) AUTO Negotiation/AUTO MDI/MDIX
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External Power Adapter (Output: 53.5 V DC / 1.31 A)
Packet Forwarding Rate 0.744 Mpps
PoE Ports (RJ45) Standard: 802.3 af/at compliant PoE Ports: Ports 1–4 Power Supply: 67 W
Mac Address Table 2K
Jumbo Frame 2 KB
Switching Capacity 1 Gbps
Dimensions ( W x D x H ) 3.9 x 3.9 x 1.0 in (100 x 98 x 25 mm)
Max Power Consumption 1.9 W (no PD connected) 74 W (with 67 W PD connected)
Max Heat Dissipation 6.5 BTU/h(no PD connected) 252.3 BTU/h(with 67 W PD connected)
SOFTWARE FEATURES
Transmission Method Store-And-Forward
Advanced Functions Compatible With IEEE 802.3af/at Compliant PDs Extend Mode Button (Ports 1–4) Priority Mode Button (Ports 1–2) Mac Address Auto-Learning And Auto-Aging IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode
OTHERS
Certification FCC, CE, RoHS
Package Contents TL-SF1005P, Power Adapter, Installation Guide
Environment Operating Temperature: 0–40 ℃ (32–104 ℉) Storage Temperature: -40–70 ℃ (-40–158 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing
WARRANTY & MANUFACTURER DETAILS
Warranty Period 3 Years
Warranty Provider Contact TP-link Service Centre for warranty
Country of Origin China
Manufacturer Details TP-Link Corporation Limited, Kowloon, Hong Kong
Importer Details TP-Link India Private Limited, Palghar, Vasai, 401208
Packer Details TP-Link India Private Limited, Palghar, Vasai, 401208
