TP-Link TL-SG1008P

SKU: FGINSUMDEHTY

8-Port Gigabit Desktop Switch with 4-Port PoE+

Original price was: ₹6,999.00.Current price is: ₹3,499.00. Inc. tax (2,965.25Exc. Tax)

Payment Methods:

Description

  • 8× 10/100/1000 Mbps RJ45 ports.
  • 4× PoE+ ports transfer data and power on the cables
  • Works with IEEE 802.3af/at compliant PDs
  • Plug and Play, no configuration and installation required
  • 802.1p/DSCP QoS enable smooth latency-sensitive traffic
  • Supports PoE power up to 30 W for each PoE port
  • Supports PoE power up to 64 W for all PoE ports*

Video: Introducing TP-Link PoE Switches

TP-Link TL-SG1008P image 0

TP-Link TL-SG1008P image 1

Dedicated 8-Port Switch with 4-Port PoE+ (64 W Budget) for Numerous Applications

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 64 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

TP-Link TL-SG1008P image 2

Plug and Play, No Configuration Required

TP-Link TL-SG1008P image 3

Intelligent Power Management

When total power consumption exceeds 64 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

TP-Link TL-SG1008P image 4

Advanced Functions for Higher Performance

TP-Link TL-SG1008P image 5

TP-Link TL-SG1008P image 6



Product Details

Brand Name TP-Link
Model Name TL-SG1008P
Dimension(cm) 22X28X7
Weight(kg) 0.98
HARDWARE FEATURES
Interface 8× 10/100/1000 Mbps RJ45 Ports AUTO Negotiation AUTO MDI/MDIX
Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External power adapter (Output: 54VDC / 1.3A)
Packet Forwarding Rate 11.904 Mpps
PoE Ports (RJ45) • Standard: 802.3 af/at compliant • PoE Ports: ports 1–4 • Power budget for all PoE ports: 64 W
Mac Address Table 4K
Jumbo Frame 16 KB
Switching Capacity 16 Gbps
Dimensions ( W x D x H ) 6.7 × 3.9 × 1.1 in (171×98×27 mm)
Max Power Consumption • 5.4 W (with no PD connected) • 75 W (with 64W PD connected)
Max Heat Dissipation • 18.4 BTU/h (with no PD connected) • 225.8 BTU/h (with 64 W PD connected)
SOFTWARE FEATURES
Transmission Method Store-And-Forward
Advanced Functions • Compatible With IEEE 802.3af/at Compliant PDs • IGMP Snooping • Mac Address Auto-Learning And Auto-Aging • IEEE802.3x Flow Control • 802.1p/DSCP QoS
OTHERS
Certification CE, FCC, RoHS
Package Contents • TL-SG1008P • Power Adapter • Installation Guide
Environment • Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
WARRANTY & MANUFACTURER DETAILS
Warranty Period 3 Years
Warranty Provider Contact TP-link Service Centre for warranty
Country of Origin China
Manufacturer Details TP-Link Corporation Limited, Kowloon, Hong Kong
Importer Details TP-Link India Private Limited, Palghar, Vasai, 401208
Packer Details TP-Link India Private Limited, Palghar, Vasai, 401208
