TP-Link VIGI C340 4mm Outdoor Full-Color Bullet Network IP CAMERA
TP-Link VIGI C340 4mm | HD Outdoor Full-Color Bullet Network Camera | CCTV Wired Security Camera | Smart IR | Two-way Audio | Waterproof IP66 | H.265+ | AI Human and Vehicle Smart Detection | Active Defense
₹6,999.00 Original price was: ₹6,999.00.₹3,399.00Current price is: ₹3,399.00. Inc. tax (₹2,880.51Exc. Tax)
Description
TP-Link VIGI C340 4mm camera includes advanced AI features like human and vehicle detection, which minimizes false alerts by focusing only on significant activities. It also supports intelligent analytics, such as line-crossing, area intrusion, and motion detection, enhancing accuracy and efficiency in real-time monitoring.
- 4MP Super-High Definition: The camera comes with 4MP–more than enough pixels to pick up some of the more discrete details.
- 24h Full-Color: Obtain 24-hour color details, even in pitch-black conditions, with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.
- Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
- Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you’ve set, obstructs the camera, or removes/abandons objects.
- Active Defense: Warn potential intruders instantly with sound and light when abnormal events.
- Two-Way Audio: Intelligently detect activities, inform you instantly and response automatically by smart detection and two-way audio.
- H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
- Smart Video Enhancement: VIGI’s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
- IP67 Waterproof: Reliable IP67 for stable outdoor performance.
- PoE/12V DC: Two types of power supply not only give you more convenience but also make your wiring remarkably easy.
- Flexible Management and Storage: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as onboard storage with SD card slot (up to 512 GB).
Clarity and Colors, All in One
Monitor 24-hour clear and colorful details even in pitch dark night. VIGI’s Full-Color camera provides maximum 4MP resolutions and ensures colorful monitoring with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.
Human & Vehicle Classification
TP-Link VIGI C340 4mm’s integrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.
Active Defense
Warn potential intruders instantly with sound and light when abnormal events
Every Event is Under Your Control.
TP-Link VIGI C340 4mm camera intelligently detect activities, inform you instantly and response automatically by smart detection and two-way audio.
SmartVid-Smart Video Enhancement
VIGI’s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
Flexible Management and Storage
Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager. Local storage is available for each methods, as well as onboard storage with SD card slot (up to 512 GB).
Run your business with peace of mind.
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
Weight | 0.43 kg |
---|---|
Dimensions | 22 × 12 × 10 cm |
Brand | |
MODEL |
VIGI C340 |
Focal Length |
4mm |
Badges |
24Hr Dispatch |
CAMERA | |
---|---|
Image Sensor | 1/3” Progressive Scan CMOS |
Shutter Speed | 1/3 to 1/10000 s |
Slow Shutter | Yes |
Aperture | 2.8 mm: F1.6 4 mm: F1.6 6 mm: F1.6 |
Lens | Fixed focal lens (2.8 mm / 4 mm / 6 mm) |
Lens Mount | M12 |
Minimum Illumination | 0 lux with IR/white Light |
Day/Night Mechanism | IR Cut Filter |
Day/Night Switch | Day/Night/Auto/Schedule-Switch |
Digital Noise Reduction | 3D DNR |
WDR | DWDR |
Weatherproof Rating | IP66 |
IR Working Distance | 30m |
Illumination Distance | 30 m |
Viewing Angle | (2.8mm) Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 122° (4mm) Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° (6mm) Horizontal FOV: 50°, vertical FOV: 27°, Diagonal FOV: 59° |
LENS | |
---|---|
Type | Fixed Focal Lens |
Focal Length | 2.8 mm/4 mm/6 mm |
Aperture | 2.8 mm: F1.6 4 mm: F1.6 6 mm: F1.6 |
FOV | 2.8mm: Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 122°4mm: Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°6mm: Horizontal FOV: 50°, vertical FOV: 27°, Diagonal FOV: 59° |
Lens Mount | M12 |
DORI Distance | 2.8 mm Detect: 64 m (209 ft) Observe: 27 m (87 ft) Recognize: 13 m (42 ft) Identify: 6 m (21 ft)4 mm Detect: 80 m (262 ft) Observe: 33 m (109 ft) Recognize: 16 m (52 ft) Identify: 8 m (26 ft)6 mm Detect: 128 m (420 ft) Observe: 53 m (175 ft) Recognize: 26 m (84 ft) Identify: 13 m (42 ft) |
Angle Adjustment (Manual) | |
---|---|
Range | Pan: -90° to 90°, Tilt: -90° to 90° |
ILLUMINATOR | |
---|---|
IR LED | Quantity: 2 Range: 30m Wavelength: 850nm |
White LED | Quantity: 2 Range: 30m |
Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
VIDEO | |
---|---|
Max. Resolution | 2560 X 1440 |
Main Stream | Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
Sub-Stream | Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 640x480, 352x288, 320x240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
Bit Rate Control | CBR, VBR |
Video Compression | Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 |
H.264 Type | Main Profile/High Profile |
H.264+ | Main Stream Supported |
H.265 Type | Main Profile |
H.265+ | Main Stream Supported |
Video Bit Rate | Main Stream: 256 Kbps to 4 Mbps Sub-Stream: 64 Kbps to 512 Kbps |
Image | |
---|---|
Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation(90°/270°) |
Image Enhancement | BLC/3D DNR/HLC/SmartIR |
Wide Dynamic Range | DWDR |
SNR | ≥ 52 dB |
Image Parameters Switch | Yes |
Privacy Mask | Up to 4 Masks |
ROI | 1 Region |
OSD Setting | Yes |
AUDIO | |
---|---|
Audio Communication | Two-Way Audio |
Audio Input | Yes |
Audio Output | Yes |
Audio Compression | Yes |
Audio Sampling Rate | 8KHz |
Environment Noise Filtering | Yes |
Audio Bit Rate | 64 Kbps(G.711 alaw) |
NETWORK | |
---|---|
Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
ONVIF | Yes |
API | ONVIF |
Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
Client | VIGI App, VIGI Security Manager |
Web Browser | Google Chrome® 57 and above Firefox® 52 and above Safari® 11 and above Microsoft® Edge 91 and above |
Cloud | Yes |
Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
Network Storage | NAS (NFS, SMB/ CIFS) |
ALARM AND EVENT MANAGEMENT | |
---|---|
Smart Event | Area Intrusion Detection, Line-Crossing Detection, People Detection |
Basic Event | Motion Detection, Video Tampering Detection, Exception ( Illegal Login) |
Alarm Linkage | Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing |
Linkage Method | N/A |
Output Notification | Message Push |
INTERFACES | |
---|---|
Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port |
Audio Input | Built-in Microphone |
Audio Output | Built-in Speaker |
Alarm | N/A |
Reset Button | Yes |
Power | DC Power Port |
Button | Reset Button |
Slot | Micro SD card |
On-board Storage | Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB |
Built-in Microphone | Yes; Records Anything Going on within a 15-ft Radius of the Camera |
Built-in Speaker | Yes |
Audio | N/A |
GENERAL | |
---|---|
Operating Temperature | -30–60 °C |
Storage Temperature | -40–60 °C |
Operating Humidity | 95% or Less (Non-Condensing) |
Storage Humidity | 95% or Less (Non-Condensing) |
Weight | 195g |
Package Contents | VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories (Screws, Drywall Anchors, Hex Key) |
Dimensions( H X W X D ) | 78 × 70 × 174 mm |
Material | Plastic |
General Features | Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening |
Power Requirements | 12V DC ± 5%, 5.5mm Coaxial Power Plug PoE (802.3af/at, class 0) |
Net Weight | 0.28 Kg |
Gross Weight | 0.42 Kg |
Power Consumption | 12V DC: Max 7.5W PoE: Class 0 |
Power Supply | 12V DC ± 5%, 5.5mm Coaxial Power Plug PoE (802.3af/at, class 0) |
Protection | IP66 |
Product Dimensions (L x W x H) | 78× 174 × 70 mm |
Certifications | CE, RCM, BSMI, VCCI, RoHS, NTRA, KC |
VIDEO/IMAGE | |
---|---|
Video Compression | Main stream: H.265+/H.265/H.264+//H.264 Sub-Stream: H.265/H.264 |
Frame Rate & Resolutions | Main Stream Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080Sub-Stream Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 640x480, 352x288, 320x240 |
Video Streaming | Main Stream Sub-Stream |
Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software |
Image Enhancement | BLC/3D DNR/Prevent Overexposure to Infrared Light |
Video Bit Rate | Main Stream: 256 Kbps to 4 Mbps Sub-Stream: 64 Kbps to 512 Kbps |
SMART FEATURE-SET | |
---|---|
Smart Event | Area Intrusion Detection, Line-Crossing Detection, Human Detection |
Basic Event | Motion Detection, Camera Tampering Detection, Exception ( illegal login) |
Linkage Method | Trigger Notification: ONVIF, HTTPS |
Region of Interest | 1 Region |
WARRANTY & MANUFACTURER DETAILS
Country of Origin | China |
Manufacturer Details | TP-Link Corporation Limited, Kowloon, Hong Kong |
Importer Details | TP-Link India Private Limited, Palghar, Vasai, 401208 |
Packer Details | TP-Link India Private Limited, Palghar, Vasai, 401208 |
