Mikrotik hap ax lite L41G-2axD

SKU: FGINQM3QYURK

Gen6 wireless on a budget – tiny, fast, and strong enough to harvest the power of RouterOS v7.

Original price was: ₹8,899.00.Current price is: ₹5,559.00. Inc. tax (4,711.02Exc. Tax)

Description

Mikrotik hap ax lite L41G-2axD

hAP ax lite is the perfect tiny solution when you’ve got to cut costs but can’t afford to sacrifice performance. Our latest Gen6 AX wireless chip allows you to squeeze the traditional 2.4 GHz wireless spectrum like a lemon! Depending on your overall setup, you can expect an increase in speed of up to 90%!

Very useful in scalable setups like hotels or expanding offices – the appealing price point, compact size, and a strong set of features allows adding more devices without a doubt! And – speaking of hotels – why not pack a hAP ax lite for your vacation? It takes up almost no space in your suitcase and allows you to break free from the restrictive guest networks.

Our hAP lite devices have always been about value. With 256 MB of RAM , a modern ARM CPU running at 800 MHz, 4x Gigabit Ethernet ports , much higher dual-chain antenna gain (up to 4.3 dBi!), and a complete visual redesign, the new hAP ax lite is a real trailblazer of value and affordable networking.

Included parts

5V 2.4A 12W USB power adapter

Wireless specifications

2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 22 -100
11MBit/s 22 -100
6MBit/s 22 -95
54MBit/s 18 -77
MCS0 22 -95
MCS7 17 -75
MCS9 16 -69
MCS11 15 -61



Ethernet test results

L41G-2axD IPQ-5010 all port test
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 202.8 2462.8 373.2 1528.5 396.8 215.9
Bridging 25 bridge filter rules 173.9 2112.3 175.8 719.9 181.5 98.7
Routing none (fast path) 202.8 2462.8 321.1 1315.4 348.4 189.6
Routing 25 simple queues 137.4 1668.1 140.2 574.4 141.9 77.2
Routing 25 ip filter rules 77.9 946.5 75.8 310.5 76 41.3
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544).
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes.
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results.

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.

Additional information
Weight 0.39 kg
Dimensions 13 × 19 × 7 cm
Product Details

Brand Name Mikrotik
Model Name L41G-2axD
Dimension(cm) 13x19x6
Weight(kg) 0.39
Product code L41G-2axD
Architecture ARM
CPU IPQ-5010
CPU core count 2
CPU nominal frequency 800 MHz
Switch chip model MT7531BE
RouterOS license 4
Operating System RouterOS v7
Size of RAM 256 MB
Storage size 128 MB
Storage type NAND
MTBF Approximately 100'000 hours at 25C
Tested ambient temperature -40°C to 70°C
Suggested price $59.00

Wireless capabilities

Wireless 2.4 GHz Max data rate 574 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz 4.3
Wireless 2.4 GHz chip model IPQ-5010
Wireless 2.4 GHz generation Wi-Fi 6
WiFi speed AX600

Ethernet

10/100/1000 Ethernet ports 4

Powering

Number of DC inputs 1 (USB-C)
Supported Voltage 5 V
Max power consumption 8 W
Cooling type Passive

Certification & Approvals

Certification CE, FCC, IC, EAC, ROHS
IP 20

Other

Mode button Yes

Warranty & Manufacturer Details

Warranty Period 1 Year
Warranty Provider Contact Fgtech Store for service warranty
Country of Origin China
Manufacturer Details SIA Mikrotlks, Unijas iela 2, Riga, LV-1039 LATVIA
Importer Details Mikrotik India, Green Park, Delhi 110016
Packer Details FGTECH INNOVATIONS LLP, Sakinaka, Andheri East, Mumbai 400072


Download Brochure

Brochure Open
Quick Guide Open
User Manual Open
Block Diagram Open
RouterOS software manual Open
Declaration of conformity Open (CE)
FCC Grant of Certification (2.4GHz) Open
RouterOS current release 1 routeros-7.14.3-arm.npk
RouterOS current release 2 wifi-qcom-7.14.3-arm.npk
