D-Link DGS-1210-12TS/ME

SKU: FGINYF137BSX

12-Port Gigabit Fiber Metro Ethernet Switch

Original price was: ₹9,999.00.Current price is: ₹4,631.00. Inc. tax (3,924.58Exc. Tax)

Payment Methods:

Description

DGS-1210-12TS/ME

  • 10 x SFP ports
  • 2 x 10/100/1000BASE-T ports
  • Comprehensive Layer 2 features including Link Aggregation, Port-based Q-in-Q, and VLAN trunking
  • Enhanced network security with IP-MAC Port-Binding (IMPB), Access Control List (ACL), and IEEE 802.1X
  • Embedded 6 kV surge protection, sub-50 ms recovery ERPS, and Dying Gasp provide optimal reliability

Ideal for Metro Ethernet

The DGS-1210ME Series Metro Ethernet Switches feature a variety of port configurations, including 10/100/1000BASE-T RJ-45 ports, 1G SFP ports, and 10G SFP+ ports for increased network bandwidth. Surge protection, advanced Layer 2 functions, and a suite of security and management tools make the DGS-1210ME Series Metro Ethernet Switches ideal for Metro Ethernet applications.
D-Link DGS-1210-12TS ME image 0

Efficient and Resilient

For mission critical environments, the DGS-1210ME Series Metro Ethernet Switches support IEEE 802.1D 2004 edition, 802.1w, and 802.1s Spanning Tree Protocols (STP). The switches also support IEEE 802.3ad link aggregation, increasing bandwidth and redundancy for higher availability. This series furthermore features IEEE 802.1p Quality of Service (QoS), allowing for real-time traffic classification into Weighted Round Robin (WRR) and strict priority levels mapped to 8 queues. Advanced traffic classification parameters allow the network to be tuned for flexible configurations for specific multimedia applications such as VoIP or IPTV.

Security & Authentication

The DGS-1210ME Series supports IEEE 802.1X port-based/host-based access control, guest VLAN, and RADIUS/TACACS+ authentication for strict access control to the network. The IP-MAC-Port Binding (IMPB) feature allows administrators to further enhance user access control. The built-in D-Link Safeguard Engine™ protects the CPU from broadcast, multicast, and unicast flooding. In addition, the Access Control List (ACL) feature enhances network security and switch performance.

D-Link DGS-1210-12TS ME image 2

Multicast Applications

The DGS-1210ME Series features a full set of L2 multicast functions, including IGMP snooping, IGMP filtering, fast leave, and multicast traffic configuration for specific ports. With L2 multicast support, the DGS-1210ME Series is ready and capable of handling growing IPTV applications.

Management Capabilities

A user-friendly web interface gives administrators access to advanced management features such as DHCP auto-configuration, allowing central management of device configurations. The switches support Link Layer Discovery Protocol (LLDP), which advertises the device’s capabilities and identity to the local network, allowing administrators to better manage their network topology. Each port also supports cable diagnostics to troubleshoot cable length and functionality problems remotely.

Traffic & Bandwidth Control

Integrated bandwidth control allows network administrators to define the throughput levels for ingress and egress bandwidth. It provides a minimum granularity of 64 Kbps for ingress port and flow-based bandwidth control, and a minimum granularity of 64 Kbps for egress queue bandwidth. The DGS-1210ME Series also supports traffic control, which optimizes overall performance, while port mirroring helps administrators perform traffic diagnostics and track network performance.



D-Link DGS-1210-12TS ME image 3



D-Link DGS-1210-12TS ME image 4

D-Link DGS-1210-12TS ME image 5

D-Link DGS-1210-12TS ME image 6



Product Details

Brand Name D-Link
Model Name DGS-1210-12TS/ME
Aggregation
8 x Link Aggregation Group Per Device 8 x Max Port Per Link Aggregation Group 802.1AX Link 802.3ad Link
Comply with RoHS 6
Yes
Console Port
Yes
CPU Speed
400MHz
DRAM Size
256MB
Flash Memory Size
32 MB
IGMP Snooping
IGMP Snooping Fast Leave Max 1024 IGMP Snooping Groups
Operating Altitude
1500 m
Power Saving
By LED Shut-Off By Link Status By Port Shut-Off By System Hibernation
Spanning Tree Protocol (STP)
IEEE 802.1D STP IEEE 802.1s MSTP IEEE 802.1w RSTP
Control
802.3x Flow
Dimensions
280 x 180 x 44 mm(11.02 x 7.08 x 1.73 in)
Energy Efficiency Ethernet (EEE)
Yes
FAN
Fanless
Head-of-line (HOL) Blocking Prevention
Yes
Humidity
Operating: 0% - 95% RH Storage: 0% - 95% RH
Interfaces
10 x 1000M SFP 10 x SFP ports 2 x 10/100/1000BASE-T ports 2 x 1000Base-T 4 x Max IP Interface
Jumbo Frame
9,216 Bytes
MAC Address Table Size
16K
Maximum Forwarding Rate
17.86 Mpps
Maximum Heat Dissipation
47.25 BTU/hr
Maximum Power Consumption
13.6 W/100 V 13.85 W/240 V
MTBF
405,083 hours
Packet Buffer Size
1.5Mbits
Power Input
100 to 240 V AC
Standby Power Consumption
7.28 W/100V 7.49 W/240V
Store & Forwarding Forwading
Yes
Switching Capacity
24 Gbps
Temperature
Operating: -5 to 50° C (23 to 122° F) Storage: -20 - 70 ˚C
Weight
1.17 kg

WARRANTY & MANUFACTURER DETAILS
Warranty Period 3yrs
Warranty Provider Contact Nearest D-link Service Centre for warranty
Country of Origin Taiwan
Manufacturer Details No. 289, Sinhu 3rd Road, Neihu District, Taipei, 114
Importer Details D-link India , Andheri Mumbai, Maharashtra 400059
Packer Details D-link India , Andheri Mumbai, Maharashtra 400059
